INSTALLATION MANUAL
SG36 HOSE REEL OPTION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SG36 and is the answer not in the manual?

Questions and answers

Related Manuals for STEELGREEN SG36

Summary of Contents for STEELGREEN SG36

  • Page 1 INSTALLATION MANUAL SG36 HOSE REEL OPTION...
  • Page 2 SG36 HOSE REEL OPTION EXPLODED VIEW PARTS LIST ITEM QTY PART NUMBER DESCRIPTION R22-072 HOSE REEL BRACKET, SG36 HFSSC-1475 HEX FLANGE BOLT 1/4 X 3/4 CB-145SS CARRAGE BOLT, 1/4 X 1/2 HFSSC-145 HEX FLANGE BOLT, 1/4-20 x 1/2 S53001 COX HOSE REEL...
  • Page 3 SG36 HOSE REEL ASSEMBLY INSTRUCTIONS STEP ONE: Disconnect the battery, ground first and then power wire. GROUND POWER STEP TWO: Disconnect the coil hose and ball valve.
  • Page 4 SG36 HOSE REEL ASSEMBLY INSTRUCTIONS STEP THREE: Disconnect and remove the fuel tank. STEP FOUR: Attach the hose reel mounting bracket. Attachment points: • Red, front tank (HFSSC-145) • Green, fuel tank bracket (CB-154SS) and (HFNCS-14S). • Blue, corner of the hopper support (HFSSC-1475) and (HFNCS-14S).
  • Page 5 SG36 HOSE REEL ASSEMBLY INSTRUCTIONS STEP FIVE: Reinstall the fuel tank. CAUTION! -Beware of excess fuel in the lines. -Fuel spillage. WARNING! -Flammable gas. STEP SIX: Attach the hose reel to the mounting bracket (HFSSC-3875) and (HFNCS-38S).
  • Page 6 SG36 HOSE REEL ASSEMBLY INSTRUCTIONS STEP SEVEN: Install the barb fitting (S52021) to the bulkhead fitting above the fuel tank. STEP EIGHT: Attach the 3/8” hose (S55005) to the hose barb fittings and securely fasten with (2) 3/8” hose clamps (MS4).
  • Page 7 SG36 HOSE REEL ASSEMBLY INSTRUCTIONS STEP NINE: Reconnect the battery, power wire first along with the pump power wire from the wiring harness, and then reconnect the ground wire. GROUND POWER...
  • Page 8 MADE IN THE USA Steel Green Mfg. 920 S State Road 39 Lebanon, IN 46052 (756)-481-2890 www.steelgreenmfg.com SG36 KIT P10039...
