Installation, Operation and Maintenance Manual
Please read and save these instructions for future reference. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety information. Failure
to comply with these instructions will result in voiding of the product warranty and may result in personal injury
and/or property damage.
Model SQ-M Direct Drive
Model SQ-M is a direct drive
centrifugal inline exhaust fan. These
fans are specifically designed for inline
applications. Performance capabilities
/hr (5,000 cfm)
3
range up to 8,500 m
and up to 498 Pa (2.0 in. wg) of static
pressure. SQ-M fans are available
in eight sizes with nominal wheel
diameter ranging from 211 to 406 mm
(8 to 16 inches) (70 to 160 unit sizes). Each fan shall
bear a permanently affixed manufacturers engraved
metal nameplate containing the model number and
individual serial number.
General Safety Information
Only qualified personnel should install this fan.
Personnel should have a clear understanding of these
instructions and should be aware of general safety
precautions. Improper installation can result in electric
shock, possible injury due to coming in contact with
moving parts, as well as other potential hazards. Other
considerations may be required if seismic activity
is present. If more information is needed, contact a
licensed professional engineer before moving forward.
1. Follow all local electrical and safety codes, as
well as the National Electrical Code (NEC) and the
National Fire Protection Agency (NFPA), where
applicable.
2. The rotation of the wheel is critical. It must be free
to rotate without striking or rubbing any stationary
objects.
3. Motor must be securely and adequately grounded.
4. Do not spin fan wheel faster than max cataloged fan
RPM. Adjustments to fan speed significantly affects
motor load. If the fan RPM is changed, the motor
current should be checked to make sure it is not
exceeding the motor nameplate amps.
5. Do not allow the power cable to kink or come in
contact with oil, grease, hot surfaces or chemicals.
Replace cord immediately if damaged.
6. Verify that the power source is compatible with the
equipment.
7. Never open access doors to a duct while the fan is
running.
®
Models SQ-M and BSQ-M
Model BSQ-M Belt Drive
Model BSQ-M is a belt drive
centrifugal inline exhaust fan. These
fans are specifically designed for inline
applications. Performance capabilities
range up to 46,200 m
and up to 996 Pa (4.0 in. wg) of static
pressure. BSQ-M fans are available in
twenty-two sizes with nominal wheel
diameter ranging from 284 to 1067 mm
(11 to 42 inches) (70 to 420 unit sizes), including High
Pressure (HP). Each fan shall bear a permanently affixed
manufacturers engraved metal nameplate containing the
model number and individual serial number.
DANGER
Always disconnect, lock and tag power source before
installing or servicing. Failure to disconnect power
source can result in fire, shock or serious injury.
CAUTION
When servicing the fan, motor may be hot enough
to cause pain or injury. Allow motor to cool before
servicing.
CAUTION
Precaution should be taken in explosive atmospheres.
Table of Contents
Receiving, Unpacking, Handling, Storage . . . . . . . 2
Inspection and Maintenance During Storage . . . . . 2
Removing from Storage . . . . . . . . . . . . . . . . . . . . . 2
Dimensional Data SQ-M/BSQ-M . . . . . . . . . . . . . . 3
Mounting SQ-M/BSQ-M . . . . . . . . . . . . . . . . . . . . . 4
Pre-Starting Checks . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Recommended Bearing Lubrication . . . . . . . . . . . 8
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Our Commitment . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Document 483064
Centrifugal Inline Fans
/hr (27,200 cfm)
3
Centrifugal Inline Fans
s
1
1
Advertisement
Table of Contents
Related Manuals for Greenheck SQ-M 70
Summary of Contents for Greenheck SQ-M 70
-
Page 1: Table Of Contents
Document 483064 Models SQ-M and BSQ-M Centrifugal Inline Fans ® Installation, Operation and Maintenance Manual Please read and save these instructions for future reference. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with these instructions will result in voiding of the product warranty and may result in personal injury and/or property damage. -
Page 2: Receiving, Unpacking, Handling, Storage
Receiving Remove any accumulations of dirt, water, ice or snow and wipe dry before moving to indoor storage. To avoid Upon receiving the product check to ensure all items “sweating” of metal parts allow cold parts to reach room are accounted for by referencing the delivery receipt or temperature. -
Page 3: Dimensional Data Sq-M/Bsq-M
Dimensional Data Figure 1: Figure 2: SQ-M Dimensions BSQ-M Dimensions 25 (1) 38 (1½) Model SQ-M Fan Dimensions Outlet Unit Housing Damper Size Velocity Weight* Material Size 229 x 229 1.828 x CFM 20 ga (12) (13) (12) ⁄ (26) (9 x 9) 305 x 305 80-90... -
Page 4: Mounting Sq-M/Bsq-M
Both options provide access only. motor. panels on two sides. Mounting Dimensional Data Model ⁄ (17) (15¾) ⁄ SQ-M 70 (13¼) (20) (18¾) ⁄ SQ-M 80-90 ⁄ ⁄ (18¾) ⁄ BSQ-M 70-90 Hanging rails not included. -
Page 5: Isolator & Discharge Information Sq-M/Bsq-M
Isolator and Discharge Information Neoprene Base Isolators Neoprene Base Isolator Model J/J1 SQ-M 70-90 (1½) (2¾) (2¾) SQ-M 100-160 ⁄ ⁄ BSQ-M 70-140 ⁄ ⁄ ⁄ ⁄ BSQ-M 160-240 ⁄ ⁄ (2½) ⁄ BSQ-M 300 ⁄ ⁄ (2½) ⁄ BSQ-M 360 Neoprene Hanging Isolator ⁄... -
Page 6: Pre-Starting Checks
Unit Size Width Height and after the fan to achieve cataloged performance. ⁄ ⁄ SQ-M 70 Side Discharge: Make sure discharge is orientated in ⁄ ⁄ SQ-M 80-90 the same direction as originally ordered, performance 302 (11 ⁄... -
Page 7: Operation
6. The adjustable motor pulley is factory set for the CORRECT WRONG RPM specified. Speed can be increased by closing or decreased by opening the adjustable motor sheave. Two groove variable pitch pulleys must be adjusted an equal number of turns open or closed. Any increase in speed represents a substantial increase in the horsepower required by a unit. -
Page 8: Maintenance
Maintenance: SQ-M / BSQ-M Installation and maintenance are to be performed only Belt/Bearing Maintenance BSQ-M Unit by qualified personnel who are familiar with local codes 1. Belts tend to stretch after a period of time. They and regulations and who are experienced with this type should be checked periodically for wear and of equipment. - Page 9 Recommended Relubrication & Frequency Intervals in Months NOTE: If unusual environment conditions exist (extreme temperature, moisture or contaminants) more frequent lubrication is required. A good quality lithium base grease, conforming to NLGI Grade 2 consistency, such as those listed here may be used.
-
Page 10: Parts List
Each fan bears a manufacturer’s nameplate with model number and serial number embossed. This information will assist the local Greenheck representative and the factory in providing service and replacement parts. Before taking any corrective action, make certain the unit is not capable of operation during repairs. -
Page 11: Troubleshooting
Troubleshooting WARNING Before taking any corrective action, make certain unit is not capable of operation during repairs. PROBLEM CAUSE CORRECTIVE ACTION Clean all dirt off wheel. Check wheel balance, rebalance in Wheel imbalance place if necessary. Bad bearings Replace. Belts too tight or too loose Adjust tension, see Figure 11. -
Page 12: Our Commitment
Our Commitment As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications without notice. Specific Greenheck product warranty is found in the Model Specification located on greenheck.co.in within the product area tab and in the Technical Data Library.
