O P E R A T I N G I N S T R U C T I O N S
AS30 Core
Array Sensor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS30 Core and is the answer not in the manual?

Questions and answers

Related Manuals for SICK AS30 Core

Summary of Contents for SICK AS30 Core

  • Page 1 O P E R A T I N G I N S T R U C T I O N S AS30 Core Array Sensor...
  • Page 2 This document is an original document of SICK AG. 2006/42/EC SAFETY O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    Possible errors during operation............. Maintenance..................30 Maintenance..................... Cleaning the device.................. 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...
  • Page 4 12.1 EU declaration of conformity..............12.2 Certification according to UL60947-5-2..........12.3 Licenses....................O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK Subject to change without notice...

  • Page 5: About This Document

    … indicates a situation of imminent danger, which will lead to a fatality or serious injuries if not prevented. 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 6: Further Information

    Before calling, make a note of all type label data such as type code, serial number, etc., to ensure faster processing. O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK...

  • Page 7: Safety Information

    8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 8: Requirements For Skilled Persons And Operating Personnel

    The device is equipped with LEDs. The device meets the criteria of risk group 1 accord‐ ing to IEC 62471:2006. No special measures are required (e.g., eye protection). O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK...

  • Page 9: Repair

    SICK AG. 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 10: Product Description

    1 = LED +3 buttons 2 = TFT +3 buttons O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK Subject to change without notice...

  • Page 11: Product Features And Functions

    Detection and positioning of an edge for highly accurate positioning (accurate posi‐ tion value). 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 12: Mounting

    25 mm / 30 mm 100 mm / 45 mm 1095581 1095582 O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK Subject to change without notice...
  • Page 13 25 mm / 30 mm 100 mm / 45 mm 1095583 1095584 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 14: Electrical Installation

    If these instructions are not complied with, the IP enclosure rating for the device is not guaranteed! O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK...

  • Page 15: Note On The Swivel Connector

    Electricity source with at least 3.1 W power • 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 16: Wiring The Interfaces

    NPN switching behavior. O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK...
  • Page 17 100 mA ! (M) ! (M) ! (M) 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 18: Operation

    To commission the device, it is necessary to accurately align the device as described in see "Mounting the device", page O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK...
  • Page 19 Edge has been taught in, Q1 and Q2 light up (depending on the Area Teach selected before) if the teach-in was successful. 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 20: Operating Elements

    (set via area teach-in - default: the whole reading field). O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK...
  • Page 21 - EDGE: an edge was detected in the field of view. 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 22: As30 Core Menu Tree

    OPERATION AS30 Core menu tree O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK Subject to change without notice...

  • Page 23: Additional Settings Via Sopas

    The AS30 Core offers 2 possible operating modes: “Edge” and “Position”. 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...
  • Page 24 The AS30 Core offers 2 possible operating modes: “Edge” and “Position”. Figure 3: Operating mode - Edge / Postition O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK...
  • Page 25 Enhanced Sensing The Enhanced Sensing menu has several functions: 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...
  • Page 26 OPERATION Figure 5: Enhanced Sensing O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK Subject to change without notice...
  • Page 27 Defining switching points or areas in the “Configuration Qint” area. 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...
  • Page 28 OPERATION O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK Subject to change without notice...

  • Page 29: Troubleshooting

    8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 30: Maintenance

    If the light emission window is scratched or damaged (cracked or broken), the device must be replaced. Contact SICK Service to arrange this. O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK...
  • Page 31 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 32: Decommissioning

    ■ Description of the fault that occurred ■ O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK Subject to change without notice...

  • Page 33: Technical Data

    Connection type Male connector M12, 5-pin Protection class 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 34: Dimensional Drawing

    Fixing hole, 4.1 mm Device connection, M12, can be rotated by 180° O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK Subject to change without notice...
  • Page 35 M12 device connection, can be rotated by 180° 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...

  • Page 36: Accessories

    Accessories can be found on the online product page at: www.sick.com/AS30 O P E R A T I N G I N S T R U C T I O N S | AS30 Core 8022080.15LJ/2020-05-07 | SICK Subject to change without notice...

  • Page 37: Annex

    Printed copies of the license texts are also available on request. 8022080.15LJ/2020-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | AS30 Core Subject to change without notice...
