Operator's Manual for:
Consumer Wheelchair Lifts
"Providing Access to the World"
International Corporate Hdqrs: P .O. Box 310
1-800-THE LIFT
30197
30197
January 2004
January 2004
TM
Vista Series
Winamac, IN 46996 USA
(574) 946-6153
FAX: (574) 946-4670
Patent #7,413,395
Patent #7,413,395
Patent #5,261,779
Patent #5,261,779
Read manual
®
®
before operating
lift. Failure to do
so may result in
serious bodily
injury and/or
property damage.
Keep manual in
lift storage pouch.
Patent #5,806,632
Patent #5,806,632
W ARNING
Patents Pending
Patents Pending

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VL955 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Braun VL955

Summary of Contents for Braun VL955

  • Page 1 Operator's Manual for: Vista Series Consumer Wheelchair Lifts "Providing Access to the World" International Corporate Hdqrs: P .O. Box 310 1-800-THE LIFT 30197 Patent #7,413,395 30197 Patent #7,413,395 January 2004 Patent #5,261,779 January 2004 Patent #5,261,779 ® ® Winamac, IN 46996 USA (574) 946-6153 FAX: (574) 946-4670 Patent #5,806,632...
  • Page 2 Congratulations We at The Braun Corporation wish to express our fullest appreciation on your new purchase. With you in mind, our skilled craftsmen have de- signed and assembled the finest lift available. This manual includes safety precautions, lift operating instructions, manual operating instructions, and instructions for maintenance and lubrica- tion procedures.

  • Page 3: Table Of Contents

    Lift Terminology Lift Terminology Illustration ... 2 Introduction ... 3 Direction ... 3 Lift Components ... 3, 4 Lift Actions and Functions ... 5 Lift Operation Safety Safety Symbols ... 6 Lift Operation Safety Precautions ... 7-10 Pre-Lift Operation Notes and Details General Safety ...

  • Page 4: Lift Terminology Illustration

    Towers (2) Module-mounted Control Switches Bridge Plate Base Plate Pump Module (Rear) Pump Side Cylinder Bottom Parallel Arms (2) Rotating Pivot Slide Arms (2) Platform Pivot Arms (2) Pump Side Vertical Arm Platform Side Plates (2) Roll Stop Activation Feet (2) Page 2 Top Parallel Arms (2) Opposite Pump Side Cylinder...

  • Page 5: Introduction

    Introduction: Braun VL955 Vista Series lifts are consumer oriented (designed to allow operation by the wheelchair passenger). VL955 lift models provide fully automatic operation of all lift functions as well as optional automatic door operators (if so equipped). Lift model VL955U3144 is de- picted in the Lift Terminology illustration.

  • Page 6: Lift Components

    Lift Components (continued) and UP/DOWN). The switches activate the automatic lift func- tions and optional door operators. Further details are provided in the Pre-Lift Operation section (page 12). Lift Frame: The lift frame consists of the base plate, two towers, the parallel arms, the vertical arms, platform pivot arms and the handrails.

  • Page 7: Lift Actions And Functions

    Lift Actions and Functions UNFOLD (Out) - Platform Unfold: Unfold is the action of the platform rotating out and down from the fully-stowed (vertical) position to floor level (horizontal) position when the OUT switch is pressed. DOWN - Platform Lower: Down is the action of the platform lowering from floor level position to fully-lowered (ground level)

  • Page 8: Lift Operation Safety

    Safety Symbols SAFETY FIRST! Know That ... All information contained in this manual and supplements (if included), is provided for your safety. Famil- iarity with proper operation instructions as well as proper maintenance procedures are necessary to ensure safe, troublefree operation. Safety precautions are provided to identify potentially hazardous situations and provide instruction...

  • Page 9: Pre-Lift Operation Notes And Details

    W ARNING If the lift operating instructions, manual operating instructions and/or lift operation safety precautions are not fully understood, contact The Braun W ARNING Corporation immedi- ately. Failure to do so W ARNING may result in serious bodily injury and/or W ARNING property damage.
  • Page 10 Lift Operation Safety Precautions (continued) Whenever a wheelchair passenger (or standee) is on the platform, the: W ARNING • Wheelchair brakes must be locked • Roll stop(s) must be up (vertical) • Passenger should grip both handrails (if able). W ARNING Load and unload clear of vehicular traffic.
  • Page 11 W ARNING instructions, manual operating instructions and/or lift operation safety precautions are not fully understood, W ARNING contact The Braun Corporation immedi- W ARNING ately. Failure to do so may result in serious bodily injury and/or property damage. W ARNING Accidental activation of control switch(es) may cause unintended operation(s).

  • Page 12: Lift Operation Safety Precautions

    Keep this operator's manual in lift-mounted manual storage pouch when not in use. W ARNING Never modify (alter) a Braun Corporation lift. W ARNING Do not use accessory devices not authorized by The Braun Corporation. Do not remove any guards or covers. W ARNING Keep clear of any hydraulic leak.

  • Page 13: Pre-Lift Operation Notes And Details

    Pre-Lift Operation Notes and Details Braun VL955 Vista Series lifts are W ARNING consumer oriented (designed to allow operation by the wheelchair Read and become passenger). VL955 Series lifts are familiar with all lift typically installed in vehicles operation safety...

  • Page 14: Lift Control Switches

    Pre-Lift Operation Notes and Details operates (clear of all moving parts). The lift occupant (passen- ger) must keep hands, arms and all other body parts within the lift Control Switches Pump Module Control Switches: The lift-mounted W ARNING Discontinue lift use immediately if any lift component does not operate properly.
  • Page 15 Braun products. Braun control systems are the only control systems authorized for use with Braun products. Do not attempt to interface aftermarket control systems with Braun products. To do so may result in serious bodily injury and/or prop- erty damage.

  • Page 16: Lift Features Bridge Plate

    When raising the platform from ground level, the platform automatically stops at floor level when raised fully. Although the VL955 features automatic floor level switching, the lift operator (wheelchair passenger or attendant), must view the platform to be certain...

  • Page 17: Automatic Outboard Roll Stop

    Pre-Lift Operation Notes and Details Fully-Folded Roll Stop (Up-vertical) Activation Feet Fully-Unfolded Roll Stop (Ramp position) Automatic Outboard Roll Stop: The outboard roll stop provides a ramp for wheelchair loading and unloading at ground level (see photos at left). When the platform lowers fully to ground level, the roll stop activation feet automatically unfold (rotate) the...

  • Page 18: Bridging

    Bridging: The VL955 incorpo- rates a bridging feature. This feature stops the down travel of the platform if the outboard end...

  • Page 19: Lift Passengers

    Although the VL955 features automatic floor level switching, it is the responsibility of the lift opera- tor to ensure the platform and...

  • Page 20: Wheelchair-Equipped Occupant Seat Belts

    Pre-Lift Operation Notes and Details Wheelchair-Equipped Occupant Seat Belts The Braun Corporation recom- mends wheelchair passengers position and buckle their wheel- W ARNING Position and secure (buckle, engage, fasten, etc.) the wheelchair-equipped occupant seat belt before loading onto the wheelchair lift platform.

  • Page 21: Preventive Maintenance

    Pre-Lift Operation Notes and Details vehicle with the sales representative on hand to ensure the lift is right for you as the end user (applicable for your use based on your physical abilities and the physical characteristics of your personal wheelchair). Become familiar with the proper operation of your lift before operating the lift by...

  • Page 22: Preventive Maintenance

    Pre-Lift Operation Notes and Details Preventive maintenance visual inspections do not take the place of the procedures speci- fied in the Maintenance and Lubrication Schedule provided W ARNING Maintenance and lubrication proce- dures must be per- formed by authorized service personnel as specified in the applicable installa- tion/service manual.

  • Page 23: Lift Operating Instructions

    If this information is not fully understood, contact The Braun Corporation immedi- ately. Failure to do so may result in serious bodily injury and/or property damage. W ARNING...
  • Page 24 Lift Operating Instructions Page 22 To Open Door(s): Automatic Door Operator(s): Press yellow OPEN switch until door(s) are fully open. Release switch. Manual Door(s): Manually open door(s) fully and secure. To Unfold Platform (Out): Press orange OUT switch until platform stops (unfolds fully – reaches floor level).
  • Page 25 Lift Operating Instructions 1. Read notes below! Load passen- 2. Press red DOWN switch until the DOWN To Unload Passenger: ger onto platform facing outward and lock wheelchair brakes. Note: Roll stop must be UP before loading passenger onto platform. Lower head to clear vehicle door jamb header.
  • Page 26 Lift Operating Instructions Page 24 To Unload Passenger: (continued) 3. Unlock wheelchair brakes and unload passenger from platform. Note: Roll stops must be fully unfolded (ramp position) until the entire wheelchair has crossed the roll stop. See Photos K and L.
  • Page 27 Lift Operating Instructions To Load Passenger: 1. Load passenger onto platform 2. Press red UP switch until platform facing outward and lock wheel- chair brakes. Note: Roll stops must be fully unfolded (ramp position) until the entire wheelchair has crossed the roll stop.
  • Page 28 Lift Operating Instructions Page 26 To Load Passenger (continued): 3. Unlock wheelchair brakes and load passenger from platform into vehicle. Note: Lower head to clear door jamb header. To Fold Platform (In): Press orange IN switch until platform stops (fully folded). Release switch.

  • Page 29: Lift Operating Instructions

    Lift Operating Instructions Automatic Door Operator(s): Manual Door(s): To Close Door(s): Press yellow CLOSE switch until door(s) are fully closed. Release switch. Manually close door(s) fully. Page 27...

  • Page 30: Manual Operating Instructions

    Manual Operating Instructions If you experience power or equip- ment failure, refer to the Manual Operating Instructions to operate the lift. Instructions and photos are provided for all steps that differ Note: Close backup pump release valve securely before operating electric pump.
  • Page 31 Manual Operating Instructions Refer to photos and illustration of release valve on previous page. Hand Pump Handle To Unfold Platform (Out): Using hand pump handle (Photo B): a. Place slotted end of pump handle onto backup pump release valve and turn counterclockwise (open —...
  • Page 32 Manual Operating Instructions Refer to photos and illustration of release valve on page 28. Open Close (Down) (Up/Stop) Page 30 • To Fold Roll Stop: • To Raise Platform: Using hand pump handle: a. Place slotted end of pump handle onto backup pump release valve and turn clockwise to close securely.

  • Page 33: Decals And Antiskid

    22249 W ARNING W ARNING Lift installation and servicing prohibited by Contact The Braun anyone who has not been certified by The Braun Corporation before adjusting hydraulic Corporation Sales and Service School. Certified pressure relief service technicians should call 1-800-THE LIFT valve.

  • Page 34: Decals And Antiskid

    Inspect your lift for any missing or worn antiskid. Order as needed. W ARNING Replace missing or worn antiskid. Failure to do so may result in serious bodily injury and/or property damage. Page 32 Decals and Antiskid Antiskid Size 2" x 12" 2"...

  • Page 35: Maintenance And Lubrication

    The VL955 has been designed with many self-lubricating compo- nents. Lubricate the pivot points specified on page 34 approxi- mately every four weeks (or 400 cycles) with a light penetrating type oil (30 weight or equivalent).

  • Page 36: Maintenance And Lubrication

    Maintenance and Lubrication Note: LPS2 General Purpose Penetrating Oil is available in eleven ounce aerosol cans from The Braun Corporation (part number 15807). Note: Clean lubrication points before applying lubricant. Outer Platform Pivot Pins (2) Roll Stop Activation Foot Pivot Point (2)

  • Page 37: Warranty And Registration Instructions

    ADDRESS CITY TELEPHONE STATE TO VALIDATE WARRANTY REGISTRATION CARDS MUST BE RETURNED TO THE BRAUN CORPORATION. Sample Warranty/Registration Card cards. The consumer must fill out the other card and mail it to The Braun Corporation. The warranty is provided on the back cover of this manual.
  • Page 38 Warranty and Registration Instructions Model No. Series No. Serial No. Page 36 Pump Code Cylinder Code Date of Manufacture Note: This information must be provided when filing a warranty claim or ordering parts. Keep for future use.
  • Page 39 "Providing Access to the World" ® Over 300 Braun Dealers Worldwide...
  • Page 40 All illustrations, descriptions and specifications in this manual are based on the latest product information available at the time of publication. The Braun Corporation reserves the right to make changes at any time without notice. at the time of publication. The Braun Corporation reserves the right to make changes at any time without notice.
