Table of contents Introduction ..................3 Features .....................3 Operating controls ................4 Operating tips ..................5 Battery installation ................6 Installation on faucet .................7 Programming ..................8 Frequently asked questions ..............9 Trouble shooting ................10 Routine maintenance ...............11 Warranty ..................12 Declaration of conformity ..............13... -
Page 3: Introduction
Introduction We are pleased you have chosen the Aquauno Logica water timer, model 8444. This Italian-made timer utilizes the most sophisticated technology and most durable material bringing you years of low maintenance and a worry-free lawn. Read instruction manual carefully before programming; save manual for future use. -
Page 4: Operating Controls
Operating controls Washable stainless steel filter 3/4” Female faucet connector with O-ring List of the 15 preset programs External ring nut Valve body Unit openings buttons (one on each side) Single-control knob ½” Female connector Male Quick-Click connector Outlet... -
Page 5: Operating Tips
Operating tips • The Logica does not allow to add or to modify the existing preset watering programs. • Use Alkaline batteries only; do not use lithium or rechargeable batteries. • Install new battery at the start of the watering season. •... -
Page 6: Battery Installation
Battery installation 1. Press the two side buttons on the front panel then insert one new 9V Alkaline battery into the terminal. 2. Replace the battery back into the housing. Notes: • Use only Alkaline batteries. • Replace the battery at the beginning of the watering season. •... -
Page 7: Installation On Faucet
Installation on faucet 1. Loosen external ring nut C. 2. Tighten 3/4” female connector A on faucet B. 3. Tighten external ring nut C to timer housing. • Do not install into any type of valve box or under the soil level. -
Page 8: Programming
Programming Simply turn the single-control knob to one of the 15 preset watering programs and the timer will start the cycle within 10 seconds; therefore it is necessary to set the timer at the exact time you want it to start watering. When a program is chosen, there will be two clicks: the first click is for battery level check and the second click opens the valve to begin watering. -
Page 9: Frequently Asked Questions
Frequently asked questions Can I change any of the preset programs or add a new water cycle? No, the Logica water timer is designed for fast and easy set-up. Can I use any 9V battery? No, Alkaline only. Do not use lithium or rechargeable batteries. What happens if the unit is not removed during freezing temperature? The ABS plastic components will crack causing the unit to be inoperable. -
Page 10: Trouble Shooting
Trouble shooting PROBLEM SOLUTION Check that the water faucet is open. Since there is no low battery indicator, if program does not start within 10 seconds of when single-control knob is turned, change the battery. The unit is not working accord- Verify that solenoid valve wires are inserted into correct outlets ing to the select- inside orange face plate. -
Page 11: Routine Maintenance
Routine maintenance • Clean impurities inside and outside the unit. • Check that all wires are in good condition. • Take apart solenoid valve case and clean dirty areas with water only. When reassembling, make sure that valve wires are in a downward position (see fig. -
Page 12: Warranty
Claber shall not be liable for damage on products manufactured by other companies when combined in use. Claber, at its own discretion, may require product or parts to be returned to the Warranty Department. All shipping charges and risks are incurred by customer. -
Page 13: Declaration Of Conformity
Via Pontebbana, 22 - 33080 - Fiume Veneto - Pordenone - Italy We hereby declare under our full responsibility that this product: 8444 - Aquauno LOGICA conforms to European Directive 2004/108/CE With reference to the technical standards defined under EN61000-6-1:2007 (immunity) and EN61000-6-3:2007 (emissions).
