IntuVue RDR-4000 Weather Radar Pilot's Guide

DISPLAY ANNUNCIATIONS

Actual annunciations are display dependent. The following figure is
provided as an example only.
WEATHER RADAR DISPLAY ANNUNCIATIONS - EXAMPLE.
D201002000008
Rev 1, December 2014
G
G
A
A
I
I
N
N
W
X
R
M
O
D
E
W
X
R
M
O
D
E
E
E
L
L
E
E
V
V
A
A
T
T
I
I
O
O
N
N
F
A
U
L
T
F
A
U
L
T
Equipment Description
Gain:
MAN GAIN
Or (blank)
Mode:
WX ALL
PATH WX
ELEVN
MAP
PWS SCAN
Elevation:
XX000 FT
or
FL XXX
Or
TURB OFF
Or (blank)
Fault:
WXR R/T
WXR RNG
WXR CTL
WXR ANT
PRED W/S
Or (blank)
33
