Industrial Router User Guide
ONV-WR300-4G
1. Technical specification
Product Name
Antenna Direction
Installation
WIFI Frequency Band
Weight
Power Supply
Material
Colour
1
4G WIFI industrial router
Omnidirectional
Wall-mounted, desktop
2.4G HZ
320g
DC 12～24V
Aluminum
Silver
Optical Network Video Technologies (Shenzhen) Co., Ltd.
+86 755 33376606

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONV-WR300-4G and is the answer not in the manual?

Questions and answers

Related Manuals for ONV ONV-WR300-4G

Summary of Contents for ONV ONV-WR300-4G

  • Page 1 Industrial Router User Guide ONV-WR300-4G 1. Technical specification Product Name 4G WIFI industrial router Antenna Direction Omnidirectional Installation Wall-mounted, desktop WIFI Frequency Band 2.4G HZ Weight 320g Power Supply DC 12～24V Material Aluminum Colour Silver +86 755 33376606 Optical Network Video Technologies (Shenzhen) Co., Ltd.
  • Page 2 Operation TEMP -20℃-55℃ Operation Humidity 10%~95% RH Non condensing Indicator and interface description Green on Power supply on Power indicator (PWR) Green off No power supply Green on LAN connection is normal LAN indicator (LAN) Green off LAN is not connected 4G network Green blink Data transmission...

  • Page 3: Installation And Configuration

    Press for one second to restart the device, press for 5 seconds to restore the Reset switch factory state. SIM card External standard SIM card slot 2.Installation and configuration 2.1 Device connection Step1: Put the SIM card into the card tray and insert it into the corresponding card slot of the device Step2: Install 3*antennas (2*2.4G WiFi antennas, 1*4G antenna) into the corresponding installation positions of the chassis.

  • Page 4: Terminal Settings

    2.2 Terminal settings The PC is set to the default "Automatically obtain IP address" and "Automatically obtain DNS server address". The device automatically assigns the P address. The device does not need to do other configuration and can automatically access the Internet by default. As shown below. +86 755 33376606 Optical Network Video Technologies (Shenzhen) Co., Ltd.
  • Page 5 +86 755 33376606 Optical Network Video Technologies (Shenzhen) Co., Ltd.

  • Page 6: Web Login

    2.3 Web login Step1: Run the web browser, enter 192.168.10.1 in the address bar, press Enter and jump to the login page, enter the login password admin, click login, and enter the router home page. Step2: After entering the home page, you can view system information, device status, SIM card information and +86 755 33376606 Optical Network Video Technologies (Shenzhen) Co., Ltd.
  • Page 7 terminal information. +86 755 33376606 Optical Network Video Technologies (Shenzhen) Co., Ltd.

  • Page 8: Network Configuration

    2.4 Network configuration Step1: Enter the interface configuration: You can modify the device IP address and set the DHCP related functions. The user can set it as needed. After the setting is completed, click <Save & Apply> to complete the setting.
  • Page 9 the user can set it as needed, and click <Save & Apply after the setting is completed > To complete the setting. Step3: Enter 3/4G configuration: Select the corresponding SIM card type according to the actual situation. Click <Save & Apply> to complete the setting. +86 755 33376606 Optical Network Video Technologies (Shenzhen) Co., Ltd.

  • Page 10: Advanced Settings

    2.5 Advanced settings Fault diagnosis: This function is mainly for developers to locate faults, users do not need to set this. +86 755 33376606 Optical Network Video Technologies (Shenzhen) Co., Ltd.

  • Page 11: System Settings

    2.6 System Settings System time: Select <Sync local time>, the device can synchronize to the current time, click <Save & Apply>, the setting will take effect. Management password: You can set a new login password, click <Save & Apply>, the setting will take effect. 2.7 Backup/Upgrade Download backup: Click <Generate Backup>, the system installation files can be backed up to a local folder.

  • Page 12: Packing List

    3. Packing List Name CONTENT UNIT Host device 4G WIFI router Power adapter Power supply Hanging ears Equipment fixed Screw pack Fixing of equipment and hanging ears 2. 4G antenna WIFI signal amplification 4G antenna 4G signal amplification User Guide User Guide (including warranty card) +86 755 33376606 Optical Network Video Technologies (Shenzhen) Co., Ltd.

  • Page 13: Warranty

    4.Note  Keep away from hazardous materials such as flammable and explosive.  Keep away from dust or dirt.  Do not expose the device to dust, dirt, sand, food, or other inappropriate substances.  To prevent falling, the equipment should be prevented from falling from a high place. ...
  • Page 14 protect your rights. Please read this clause carefully. Quality Commitment: Adhering to the tenet of "Users are God", the company provides customers with high-quality and satisfactory after-sales service. We promise to provide free warranty service within one year for all products sold by our company.
  • Page 15 (the team bare board) is considered to cause product damage, such as chip burnt, mainboard, shield cover damage, radiofrequency head damage, etc. 3. Other problems and malfunctions caused by abnormal use (mainly the power supply part or non-ONV +86 755 33376606...
  • Page 16 7. Product information is incomplete, such as the warranty sticker/MAC address/SN code affixed to the body, the date paper is removed, damaged, or altered, and the model sticker is torn off; 8. Change the firmware of non-ONV company without authorization +86 755 33376606...
  • Page 17 Customer Profile Name Contact number Model Postal code MAC number Sales name Contact number Sale date Postal code Sales address Date Fault description Maintenance records Remarks +86 755 33376606 Optical Network Video Technologies (Shenzhen) Co., Ltd.
  • Page 18 Remarks 1. The return freight will be paid by both parties. 2. For goods that are returned for repair, the customer is requested to report the abnormal quality within 7 days after receiving the product (based on the date of the courier number), and the overdue will not be negative. 3.
  • Page 19 Optical Network Video Technologies (Shenzhen) Co., Ltd. Tel: 0086-755-33376606 Fax: 0086-755-33376608 Email: onv@onv.com.cn Website: www.onvcom.com Zip: 518000 Headquarter Address: Room 1003, Block D, Terra Building, Futian District, Shenzhen,China Factory Address:The 4-6th Floor, No. 59, Huaning Road, Xinwei Community, Dalang Street,...
