AIRLESSCO 25M223 Operation - Repair - Parts

Striping gun
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operation/Repair/Parts
Airlessco Striping Gun
For professional use only.
For the application of architectural paints and coatings.
5000 psi (34.5 MPa, 345 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual and in related manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
Model: 25M223
Includes 69317ST & 69319ST tips
ti30164a
3A4408B
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 25M223 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AIRLESSCO 25M223

Summary of Contents for AIRLESSCO 25M223

  • Page 1 Operation/Repair/Parts 3A4408B Airlessco Striping Gun For professional use only. For the application of architectural paints and coatings. 5000 psi (34.5 MPa, 345 bar) Maximum Working Pressure Important Safety Instructions Read all warnings and instructions in this manual and in related manuals.

  • Page 2: Table Of Contents

    Technical Data ........15 Airlessco Standard Warranty ......16...

  • Page 3: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings.
  • Page 4 Check hoses and parts for signs of damage. Replace any damaged hoses or parts. • This system is capable of producing 4000 psi. Use Airlessco replacement parts or accessories that are rated a minimum of 4000 psi. • Always engage the trigger lock when not spraying. Verify the trigger lock is functioning properly.
  • Page 5 Do not kink or over-bend the hose. • Do not expose the hose to temperatures or to pressures in excess of those specified by Airlessco. • Do not use the hose as strength member to pull or lift the equipment.

  • Page 6: Component Identification

    Component Identification Component Identification ti30165a Tip guard Trigger lock Trigger Fluid inlet Hose guard 3A4408B...

  • Page 7: Setup

    Setup Setup Pressure Relief Procedure Put drain tube into a waste pail and turn Prime/Spray valve in PRIME position (drain) to relieve pressure. Follow the Pressure Relief Procedure whenever you see this symbol. ti30176a Hold the gun firmly to a pail. Point gun into pail.

  • Page 8: Gun Trigger Lock

    Setup Gun Trigger Lock Connect Gun to Sprayer Make sure sprayer is turned off and unplugged from power source. Refer to your sprayer instruction manual for priming and spray instructions. To prevent injury when the gun is not in Attach supply hose to sprayer fluid use, always engage the gun's trigger lock if outlet.
  • Page 9 Setup Verify spray tip and tip guard parts are Screw spray tip and tip guard assembly assembled in the order shown. on to the gun and tighten. Use spray tip to align gasket and seal in the tip guard. Spray tip must be pushed all the way into the tip guard.

  • Page 10: Operation

    Operation Operation NOTE: If spray tip is difficult to rotate when turning to the unclog position, perform Pressure Relief Procedure, page 7, then turn Prime/Spray valve to spray position and repeat step 1. Spray Engage trigger lock. Rotate spray tip back to spray position.

  • Page 11: Repair

    Repair Repair Unscrew diffuser/seat and remove. To avoid personal injury, always read all warnings in this manual, and the equipment manual, before performing any repairs on the gun. Disassemble ti30182a Perform Pressure Relief Procedure, Unscrew pivot pin from screw and page 7.

  • Page 12: Reassemble

    Repair Insert punch into rear of gun. Tap out Guide new needle into gun. needle. ti30197a ti30184a An insertion tool is provided in needle kit 235474. This tool helps prevent damage to Cleaning needle. Clean all parts and cavities thoroughly with Position insertion tool from kit over end of needle.
  • Page 13 Repair Grease tip of new needle. Slide trigger into place and attach with pivot pin and screw. ti30262a Grease threads of diffuser/seat. Place gasket on diffuser/seat. ti30263a Screw diffuser/seat onto gun nozzle. ti30199a Torque to 20-25 ft-lb (27-34 N•m). Attach tip and guard and attach gun to fluid hose.

  • Page 14: Parts

    Parts Parts 25M223 ti30200a Ref. Part Description Qty. Ref. Part Description Qty. 11 218139 GUARD, hose 25M521 HANDLE, gun 13 107257 SCREW, thd forming 187972 HOUSING, valve, needle 14 187965 PIN, pivot 235474 VALVE, needle 15 203953 SCREW, cap, hex hd...

  • Page 15: Technical Data

    Technical Data Technical Data Metric Dimensions Weight (includes tip and tip 21.4 oz. 607 g guard): Height: 9.5 in. 241 mm Length (handle extended): 7.25 in. 184 mm Sprayer Maximum Working Pressure 5000 psi 345 bar, 34.5 MPa Fluid Orifice Size 0.125 in.

  • Page 16: Airlessco Standard Warranty

    Airlessco, Airlessco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Airlessco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with Airlessco’s written recommendations.
