Acnodes APM 5064 Specifications

» Specifications
Material:
Industrial 6mm Aluminum front bezel
LCD Panel:
Size: 6.4 inch diagonal (129.6H x 97.44V)
Brightness: 300 cd/m2
Resolution: 640 x 480, VGA
Contrast Ratio:
180 : 1 (Typical)
Pixel Pitch: 0.203 x 0.203 mm
Responsible time: 20ms (rise), 30ms (fall)
Display Color: 262,144 color
Viewing Angle:
55 / 55 / 15 / 35 (L / R / U / D)
LCD LLT: 20,000 hrs
Optional for AV-input (S-video / Composite)
Touch Screen (Optional):
Touch type: Resistive / Capacitive
Thickness: 1.8mm VGA 640 x 480
Light transmission:
Resistive-type:75%
Capacitive-type:85%
Controller Interface: Serial / USB
Durability:
Resistive-type: 35 Million
Capacitive-type: 225 Million
OS Support Windows:
XP, 2000, NT, 98, DOS and Linux
On Screen Control:
OSD Control Brightness, Contrast, Phase & Clock,
Color, H & V position, Auto-tune & Recall
External Power Adapter:
AC Input: 110V ~ 220V
DC Input: 12V@3A Output
AC Cable: Length 180cm
DC Cable: Length 182cm
Adapter Size: 108(L) x 64(W) x 30(H) mm
Safety Approval: UL, CE
20957 Currier Road Suite #D
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
APM 5064
6.4" 640 x 480 TFT LCD
Aluminum front bezel
Panel / VESA mount ready
» Features
» Panel mount LCD monitor,
» 6.4" 640x480 TFT LCD display
» OSD (On Screen Display) function
» VESA-mount or wall-mount ready
» 15-pins VGA connector, optional for s-video / composite
» External 110/220VAC power adapter
Connectors:
1 x D-Sub 15 pin (female) for VGA
Optional for: S-Video and Composite
Color:
Black
Mounting -type:
Panel mount: mounting bracket (included)
wall-mount / VESA arm: 75mm VESA mounting holes
Environmental:
Operating Temperature: -20 to 70oC
Storage Temperature: -30 to 70oC
Humidity: 95%, non condensing
Shock: 10G peak acceleration, ( 11ms, half since wave)
Gross Weight:
7.5 lb
Dimension:
230(W) x 167(H) x 51(D) mm
Safty ertification:
CE, FCC
» Ordering Guide
APM 5064:
6.4" 640 x 320 panel mount LCD monitor with Aluminum
front bezel
» Options
APM 5064T: 6.4" with RS-232 resistive-type touch screen
APM 5064TU: 6.4" with USB reistive-type touch screen
© Copyright 2007 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes' web site at www.acnodes.com.
51mm depth
