Sencor SVS 1010WH Manual page 6

3. AIR SUCTION FROM AN EXTERNAL VACUUM CONTAINER
FUNCTION
3.1 Place foodstuffs into the vacuum container (not included). Close the
container with its lid. Connect the wider connector on hose A11 to
the air suction inlet A9. Connect the narrower connector to the hole
in the lid of the container.
3.2 Press the button for turning on air suction from an external container
A8. When the air suction process is complete, the appliance will turn
off automatically.
3.3 First disconnect the connector from the hole in the lid and only then
disconnect the connector from the air suction inlet A9.
3.4 To extend the storage life of the foodstuffs in the vacuum container,
place this container into a refrigerator.
3.5 Before removing the foodstuffs from the container, first press the
button on the lid to release the vacuum. Only then open the lid.
3.6 Remove the lid from the vacuum container before heating in
a microwave.
Note:
The air suction process can be ended at any time by again
pressing button A8.
■
When a bag is melted, it is necessary to wait 5 minutes for the sealing
strip A2 to cool down.
■ A rest period of at least 40 seconds should be maintained between
the sealing cycles to allow the appliance to cool down. Leave the
lid A1 open during the rest period. The maximum operating time is
15 minutes. Then allow it to cool down for approximately 30 minutes.
■ When you have finished, disconnect the power cord from the power
socket and allow the appliance to cool down. Clean out the appliance
after each use according to the instructions in chapter Cleaning and
maintenance.
ADVICE AND RECOMMENDATIONS
■ Do not overfill the bags. Leave sufficient free space inside them so
that you can insert the open side into the vacuum sealer and to easily
close its lid A1. Fill the vacuum containers so that there is at least
2.5 cm of free space under the edge.
■ Make sure that the open side of the bag that is inserted into the
vacuum sealer is clean, dry and free of creases. Moisture or creases
may result in a strong seal not being created or a seal not being
created at all.
■
Vacuum sealed packaging cannot substitute for storing foodstuffs
in a refrigerator or freezer. Place foodstuffs contained in a vacuum
package that spoil quickly into a refrigerator or freezer. This will
extend their storage life.
■
If you wish to vacuum seal items of larger dimensions, straighten
the open side of the bag before inserting it into the vacuum sealer.
■ We recommend wrapping items with sharp edges or dry pasta in
paper tissue before placing them into a vacuum sealer bag. This will
protect it against damage.
■
If you are not certain that the seal is sufficiently strong, seal the bag
once more to make sure.
■ The sides of the original vacuum sealer bags are sealed along their
entire length all the way to the edges. Do not attempt to adjust them,
otherwise the vacuum may be compromised.
■
Bag sealing problems may arise for foodstuffs with a higher moisture
content. In the event that such a situation arises, remove a part of
the foodstuffs, thoroughly clean the edge of the bag and attempt
to seal it again.
■
The tightness of the vacuum sealer bag can be verified by submerging
it in water. Bubbles will come out of the bag from the unsealed
location.
■ Foodstuffs will spoil unless a complete vacuum is created in the bag.
Spoiled foodstuffs must be disposed of.
■
Do not use vacuum sealer bags repeatedly if they contained raw
meat, fish, greasy foodstuffs, etc. or if you heated foodstuffs in them
in a microwave oven or in boiling water.
Copyright © 2017, Fast ČR, a.s.
FOOD STORAGE TIME
REFRIGERATOR, TEMPERATURE 5 °C (±2 °C)
Food type
Red meat
White meat
Fish
Cooked meat
Soft cheese
Semi-hard and hard cheese 15–20 days
Fruit
Vegetables
Soups
Cooked pasta/rice
Cream desserts
ROOM TEMPERATURE 25 °C (±2 °C)
Food type
Fresh bread
Biscuits
Pasta/rice (in raw state)
Flour
Dried fruit
Ground coffee
Loose tea
FREEZER, TEMPERATURE –18 °C (±2 °C)
Food type
Meat
Fish
Vegetables
CLEANING AND MAINTENANCE
■ Before cleaning, disconnect the power cord from the power socket
and allow the appliance to cool down.
■ Remove any remains or liquids from the vacuum chamber A6. Then
clean it with a lightly dampened cloth and thoroughly wipe dry.
■ To clean the external surfaces, use a cloth lightly dipped in water
with neutral kitchen detergent. Then wipe everything so that it is
thoroughly dry.
■
For cleaning, never use steel wool, abrasive cleaning products,
solvents, etc.
Attention:
Do not submerge the appliance or its power cord in water or
any other liquids.
TECHNICAL SPECIFICATIONS
Rated voltage range ............................................................................. 220−240 V
Rated frequency .............................................................................................. 50 Hz
Rated power input .........................................................................................110 W
Electrical shock protection class ......................................................................... II
Noise level. ................................................................................................... 75 dB(A)
Maximum vacuum pressure ................................................................... –0.8 bar
Compressor power .....................................................................................12l/min
Maximum roll and bag width .................................................................... 30 cm
The declared noise emission level of the appliance is 75 dB(A), which
represents a level A of acoustic power with respect to a reference acoustic
power of 1 pW.
Explanation of technical terminology
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by double or heavy-
duty insulation.
We reserve the right to change text and technical specifications.
- 6 -
Not vacuum sealed Vacuum sealed
3–4 days 8–9 days
2–3 days 6–8 days
1–3 days 4–5 days
3–5 days 10–15 days
5–7 days 20 days
60 days
5–7 days 14–20 days
1–3 days 7–10 days
2–3 days 8–10 days
2–3 days 6–8 days
2–3 days 8 days
Not vacuum sealed Vacuum sealed
1–2 days 8–10 days
4–6 months 12 months
5–6 months 12 months
4–6 months 12 months
3–4 months 12 months
2–3 months 12 months
5–6 months 12 months
Not vacuum sealed Vacuum sealed
4–6 months 15–20 months
3–4 months 10–12 months
8–10 months 8–24 months
05/2017
