- Page 1 Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
- Page 2 FAR 27.401 or DFAR could result in personal injury or death. 227.7103-5 (c), as applicable in any Do not proceed beyond a WARNING technical data. notice until the indicated conditions are fully understood and met. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
-
Page 3: Table Of Contents
..........30 Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... - Page 4 ........34 Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
- Page 5 ....20 Figure 2-10 Connecting the BroadR-Reach (100BASE-T1) Cable to the 100BASE-T1/Ethernet Media Converter ..20 Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
- Page 6 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
- Page 7 ....... . .23 Table A-1 Abbreviation and Definition .....32 Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
- Page 8 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
- Page 9 Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide Product Inspection Check the Product...
-
Page 10: Product Inspection
Product Inspection Check the Product Upon receiving the APM0100E 100BASE-T1/Ethernet Media Converter from Keysight Technologies, perform the following product inspection: – Inspect the outer shipping container, foam-lined instrument case, and product for damage. – Retain the outer cardboard shipping container until you have inspected the contents of the shipment for completeness, and you have checked the product mechanically and electrically. -
Page 11: Figure 2-5 100Base-T1/Ethernet Media Converter Hardware Setup
Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide Introduction Overview Operation and Features Interfaces and Indicators 100BASE-T1/Ethernet Media Converter Hardware Setup Technical Specifications... -
Page 12: Introduction
Converter is packaged in a rugged, lightweight enclosure, making it easy to take anywhere it's needed. The 100BASE-T1/Ethernet Media Converter is ideal for monitoring, analysis, diagnostics, and other applications in an Automotive Ethernet environment. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 13: Operation And Features
The following lists the features of the 100BASE-T1/Ethernet Media Converter: – Powered by an industry-standard mini-USB connection – Broadcom BCM89810 BroadR-Reach (100BASE-T1) PHY – Automatic master/slave configuration for the attached Automotive Ethernet device Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 14: Figure 2-1 100Base-T1/Ethernet Media Converter Block
100BASE-T1/Ethernet Media Converter. The two PHYs are connected directly to each other via the standard Ethernet Media Independent Interface (MII). Figure 2-1 100BASE-T1/Ethernet Media Converter Block Diagram Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 15: Interfaces And Indicators
– Mini-USB Port: A standard mini-USB port that provides power to the device. Activity LED Link LED RJ-45 Port Mini USB Port Figure 2-2 100BASE-T1/Ethernet Media Converter Conventional Ethernet Side Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 16: Automotive Ethernet Side
Automotive Ethernet device and remains on as long as the link is maintained. – Err (Red): Flickers upon detection of an error by the 100BASE-T1/Ethernet Media Converter's BroadR-Reach (100BASE-T1) PHY, such as detecting a data transmission error in a received frame. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 17: Figure 2-4 100Base-T1/Ethernet Media Converter Broadr-Reach (100Base-T1) Molex Mini50 Jack With Pin Numbers
No Connect – Pins are numbered 1 to 4 from left to right looking at the jack shown in Figure 2-4. Figure 2-4 100BASE-T1/Ethernet Media Converter BroadR-Reach (100BASE-T1) Molex Mini50 Jack with Pin Numbers Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 18: 100Base-T1/Ethernet Media Converter Hardware Setup
2 Connect USB Cable to PC or USB Hub. Attach the larger USB connector on the USB cable to an open USB port on a PC or a USB hub shown in Figure 2-6. Figure 2-6 Connecting the USB Cable to a Laptop USB Port Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 19: Figure 2-7 Connecting The Usb Cable To The 100Base-T1/Ethernet Media Converter
Ethernet cable to 100BASE-T1/Ethernet Media Converter. When you power on the PC or other Ethernet devices, you should now see the Link LED lighting up and remain lit; the Activity LED may also begin to flash. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 20: Figure 2-9 Connecting The Ethernet Cable To The 100Base-T1/Ethernet Media Converter
Your 100BASE-T1/Ethernet Media Converter is now ready for operation. Figure 2-10 Connecting the BroadR-Reach (100BASE-T1) Cable to the 100BASE-T1/Ethernet Media Converter If you experience any issues setting up the hardware, refer to “Troubleshooting” NOTE on page 25. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 21: Technical Specifications
Details on the 100BASE-T1/Ethernet Media Converter's USB connection: – Industry-standard USB 2.0 – Mini-USB connector – Device powered via USB connection – Power draw: 250 mA @ 5 V – Power consumption: about 1.25 W Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 22: Ethernet Transceivers/Phys
Characteristics for the Standard Ethernet (100BASE-TX) Transceiver Characteristic Description Model Texas Instruments DP83848CVVX/NOPB Speed and MAC method 10/100 Mb/s, half/full-duplex, auto-negotiated Connector RJ-45 Transmission latency (MII to wire) 60 ns Reception latency (wire to MII) 240 ns Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 23: Other Specifications
100BASE-T1/Ethernet Media Converter. Table 2-5 Other Specifications for 100BASE-T1/Ethernet Media Converter Specification Description Housing materials Anodized aluminum and rubber Operating temperature range -40 °F (-40 °C) to 185 °F (85 °C) IP Code IP30 Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... - Page 24 Introduction THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
- Page 25 Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide Troubleshooting No LEDs are Illuminated Conventional Ethernet Link LED is not Illuminated Automotive Ethernet Link LED is not Illuminated Err LED Lights Up Data Sent by the Automotive Ethernet Device is Not Received...
-
Page 26: Troubleshooting
– Try a different USB cable – Try connecting to a different USB device If the supplied USB cable that came with the 100BASE-T1/Ethernet Media Converter does not work, but a different USB cable does, contact Keysight “Service and Support” on page 34. -
Page 27: Conventional Ethernet Link Led Is Not Illuminated
– Disable and then re-enable the Ethernet port within Windows on the PC If the supplied Ethernet cable that came with the 100BASE-T1/Ethernet Media Converter does not work, but a different Ethernet cable does, contact Keysight “Service and Support” on page 34. -
Page 28: Automotive Ethernet Link Led Is Not Illuminated
If you are connecting the 100BASE-T1/Ethernet Media Converter to a shared NOTE Ethernet network-one that uses hubs rather than switches — you may see more errors than usual. However, very few modern networks are set up in this manner. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... -
Page 29: Data Sent By The Automotive Ethernet Device Is Not Received
If the Activity LED is lighting up, reattach the BroadR-Reach (100BASE-T1) cable to the 100BASE-T1/Ethernet Media Converter, and check the connection to the Automotive Ethernet device. Try with a new cable if possible. If you are unable to resolve the issue, contact Keysight “Service and Support” page 34. -
Page 30: Difficulty Removing The Broadr-Reach (100Base-T1) Cable From The Molex Mini50 Jack
Ensure you press on the small tab in the middle of the cable connector all the way down before attempting to pull it out of the jack. Do not pull the plug out by the wires, or you may damage the cable. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... - Page 31 Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide Appendix List of Abbreviations...
-
Page 32: Table A-1 Abbreviation And Definition
Appendix List of Abbreviations Table A-1 Abbreviation and Definition Abbreviation Definition Device under test Electronic/Engine Control Unit Media Access Control Media Independent Interface Transmit/Receive data Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide... - Page 33 Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide Appendix Service and Support...
- Page 34 800 810 0189 0120 (421) 345 1 800 375 8100 Hong Kong Korea Taiwan 800 938 693 080 769 0800 0800 047 866 Other Asian Countries: (65) 6375 8100 www.keysight.com/find/contactus Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
- Page 35 Switzerland 0805 980 333 0800 80 53 53 +32 800 58580 *0.125 €/minute United Kingdom Netherlands Germany 0800 0260 637 0800 0233 200 0800 6270 999 Other Unlisted Countries: www.keysight.com/find/contactus Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
- Page 36 Appendix THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight APM0100E 100BASE-T1/Ethernet Media Converter User Guide...
- Page 37 This information is subject to change without notice. Always refer to the English version at the Keysight website for the latest revision. © Keysight Technologies 2020 February 2020 www.keysight.com...
