- Page 2 ADDAC402 EXPANSION MIDI GUIDE Revision.01 January.2017 INTRODUCTION ADDAC402B MIDI Expansion allows full I/O Midi control of ADDAC402 plus access to a powerfull midi inter- face, with: Midi Sync: Allows the module to synchronize with any external MIDI device’s Clock, including transport messages like play, stop and continue.
-
Page 3: Menu Description
ADDAC402 EXPANSION MIDI GUIDE Revision.01 January.2017 MENU Description For any MIDI Configuration the user must get into the CONFIG Menu, this is done by pressing the MODE INFO / CONFIG push button for 3 seconds, after this the screen will show the first Menu Page:... - Page 4 ADDAC402 EXPANSION MIDI GUIDE Revision.01 January.2017 MIDI GENERAL CONFIGURATION The General Configuration Menu page allows the User to configure: MIDI SOFT THRU ON / OFF CLOCK TYPE OFF / SLAVE CLOCK DIV 6 to 48 REMOTE CONTROL ON / OFF...
- Page 5 ADDAC402 EXPANSION MIDI GUIDE Revision.01 January.2017 MIDI IN CONFIGURATION MENU MIDI CHANNEL OFF to 16 MODE CHG CC OFF to 119 MIDI INPUT CONFIGURATION PRESET CHG OFF to 119 CLOCK CC OFF to 119 The MIDI Input Menu page allows the User to configure:...
- Page 6 ADDAC402 EXPANSION MIDI GUIDE Revision.01 January.2017 MIDI IN CONFIGURATION MENU MIDI CHANNEL OFF to 16 MODE CHG CC OFF to 119 MIDI INPUT CONFIGURATION PRESET CHG OFF to 119 CLOCK CC OFF to 119 (continued) PLAY/PAUSE CC OFF to 119...
- Page 7 ADDAC402 EXPANSION MIDI GUIDE Revision.01 January.2017 MIDI OUT CONFIGURATION MENU MIDI CHANNEL OFF to 16 MODE CHG CC OFF to 119 MIDI OUTPUT CONFIGURATION PRESET CHG OFF to 119 CLOCK CC OFF to 119 The MIDI Output Menu page allows the User to configure:...
- Page 8 ADDAC402 EXPANSION MIDI GUIDE Revision.01 January.2017 MIDI OUT CONFIGURATION MENU MIDI CHANNEL OFF to 16 MODE CHG CC OFF to 119 MIDI OUTPUT CONFIGURATION PRESET CHG OFF to 119 CLOCK CC OFF to 119 (continued) PLAY/PAUSE CC OFF to 119...
- Page 9 For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC402 EXPANSION MIDI GUIDE Revision.01 January.2017...
