Specifi cations
Camera Unit (CMOS-300)
Output video
: Wide-angle mirror image (for rearview)/wide-
angle normal image (for front view)
Sensor: 1/4-inch color CMOS sensor
Number of pixels: Approx. 310,000 pixels
Lens
: Wide angle, focal length f=0.82mm, F value 2.6
Angles of view
: Horizontal: Approx. 190°
: Vertical: Approx. 158°
Illumination range
: Approx. 0.9 to 100,000 lux
Iris system: Electronic iris
Scanning system: Interlace
Synchronizing system: Internal synchronization
Video output: 1Vp-p/ 75Ω
Dimensions (WxHxD): 24 x 24 x 24.8 mm
Weight: Approx. 30 g (without cable)
Camera Unit (CMOS-200)
Output video
: Wide-angle mirror image (for rearview)
Sensor: 1/4-inch color CMOS sensor
Number of pixels: Approx. 310,000 pixels
Lens
: Wide angle, focal length f=1.6mm, F value 2.3
Angles of view
: Horizontal: Approx. 135°
: Vertical: Approx. 105°
Illumination range
: Approx. 0.9 to 100,000 lux
Iris system: Electronic iris
Scanning system: Interlace
Synchronizing system: Internal synchronization
Video output: 1Vp-p/ 75Ω
Dimensions (WxHxD): 24 x 24 x 24.8 mm
Weight: Approx. 29 g (without cable)
Switch Unit (CMOS-300 only)
Dimensions (WxHxD): 27.5 x 32.8 x 12 mm
Weight: Approx. 10 g (without cable)
Power Supply Box Unit
Operating voltage
: 14.4V (11V – 16V)
Max. current consumption (CMOS-300)
: 150mA
Max. current consumption (CMOS-200)
: 100mA
Dimensions (WxHxD): 54 x 23 x 22 mm
Weight: Approx. 32 g
• Mirror image means that the video image inverts the left
and right just like the image seen on the rearview mirror or
a side mirror.
• Specifications subject to change without notice.
This symbol mark indicates that
Kenwood manufactured this product so
as to decrease harmful influence on the
environment.
This Product is not installed by the manufacturer of a
vehicle on the production line, nor by the professional
importer of a vehicle into an EU Member State.
Information on Disposal of Old Electrical
and Electronic Equipment and Batteries
(applicable for EU countries that have
adopted separate waste collection systems)
Products and batteries with the symbol
(crossed-out wheeled bin) cannot be
disposed as household waste.
Old electrical and electronic equipment and
batteries should be recycled at a facility
capable of handling these items and their
waste byproducts.
Contact your local authority for details in
locating a recycle facility nearest to you.
Proper recycling and waste disposal will help
conserve resources whilst preventing
detrimental effects on our health and the
environment.
Notice: The sign "Pb" below the symbol for
batteries indicates that this battery
contains lead.
For Turkey
Bu ürün 26891sayılı Resmi Gazete'de yayımlanan Elektrikli
ve Elektronik Eşyalarda Bazı Zararlı Maddelerin Kullanımının
Sınırlandırılmasına Dair Yönetmeliğe uygun olarak
üretilmiştir.
This product complies with Directive, Number 26891
regarding "REGULATION ON THE RESTRICTION OF THE USE
OF CERTAIN HAZARDOUS SUBSTANCES IN ELECTRICAL AND
ELECTRONIC EQUIPMENT".
15
|
English
