Provide a copy of these Instructions to the end user of this product. These Instructions provide
Dealer /
important operating and safety information for proper usage of this product. Demonstrate the
Installer:
proper use of the product with the end user. Have the end user demonstrate that they understand
the proper use of the product.
Read and follow all instructions included in this manual. Ask your Dealer / Installer for assistance
End
if you do not understand the proper use of the product. Never remove any decals from the
User:
product.
NOTE: This bracket kit is to be used with the 31323 4 Bolt Bed Rail Kit or 30686 10 Bolt Bed Rail Kit.
Item No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Tools Required
11/16" Socket & Wrench
3/4" Socket & Wrench
15/16" Socket & Wrench
Torque Wrench
Safety Glasses
Base Rails Not Included
All Products limited to Vehicle Tow Rating, see Vehicle Owners Manual. See www.huskytow.com for Warranty
Information / Tech Support / Product Updates. ©2017 DTS Mfg. All Rights Reserved. April 4, 2017-Rev14
Assembly, Installation, Operation and Maintenance Instructions
Kit, Base Rail Bracket
APPLICATION: 2004 – 2014 FORD F150 PICK-UPS
COMPLETE PARTS LIST
Driver Side Front Bracket
Passenger Side Front Bracket
Driver Side Rear Bracket
Ø5/8" -11 X 3.25" Grade 5 Hex Head Bolt
Ø1/2" -13 X 4-3/4" Grade 5 Hex Head Bolt
Ø7/16" -14 X 2" X 1.41" U-Bolt
Ø7/16" -14 Grade 5 Hex Nut
WARNING! Never exceed the towing capacity of the
tow vehicle.
Center Bolt Kit 32059 (sold separately) must be used
when towing with a 26K hitch, Goose Neck, or
Maneuvering System.
CAUTION: Do not install base rails over plastic bed liners.
Plastic bed liners must be cut out of the way. Rails may be
installed on spray in liners. Consult spray liner installer for
recommended curing time.
Description
Passenger Side Rear
Rear Mounting Strap
1/4" Spacer Plate
1" Spacer Tube
Ø5/8" Flat Washer
Ø5/8" - 11 CLIP NUT
Ø5/8" Lock Washer
Ø1/2" Flat Washer
Ø1/2" -13 Nylock Nut
Ø7/16" Flat Washer
Ø7/16" Lock Washer
Pull Wire
Page 1 of 8
Part # 31564
Quantity
1
1
1
1
2
4
4
4
4
4
4
4
4
4
2
4
4
4
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Husky 31564
Summary of Contents for Husky 31564
- Page 1 Assembly, Installation, Operation and Maintenance Instructions Kit, Base Rail Bracket Part # 31564 Provide a copy of these Instructions to the end user of this product. These Instructions provide Dealer / important operating and safety information for proper usage of this product. Demonstrate the Installer: proper use of the product with the end user.
- Page 2 All Products limited to Vehicle Tow Rating, see Vehicle Owners Manual. See www.huskytow.com for Warranty Information / Tech Support / Product Updates. ©2017 DTS Mfg. All Rights Reserved. April 4, 2017-Rev14 Page 2 of 8...
- Page 3 1. Locate the two holes in the outer surfaces of the truck frame behind the shock mount. Place the pull wire on one leg of u-bolt #16 as shown in Figure 2 and install u-bolt into the two holes in truck frame. U-Bolt #16 Pull Wire # 20 Front of Truck...
- Page 4 FRONT 2. Position the driver side front bracket #1 against the truck frame so previously installed u-bolt extends out through the two holes in bracket. Bolt bracket loosely in place as shown on Figure 3. Repeat installation procedure on passenger side of truck using the passenger side front bracket #2.
- Page 5 5. Drill a ¼” pilot hole down through the end square hole in each base rail. Check under bed to see that holes line up with slots in top of previously installed frame brackets. Make adjustments in base rail placement as needed. Move base rail assembly away from hole locations and drill a 5/8”...
- Page 6 5/8” X 11 HEX BOLT #8 5/8” LOCK WASHER #11 5/8” FLAT WASHER #9 5/8” CLIP NUT #10 Base Rail SPACER TUBE #7 SPACER PLATE #6 Truck Bed Corrugation 5/8” CLIP NUT #10 Truck Frame Driver Side Front BRACKET #1 SHOWN Front of Vehicle Driver Side Front...
- Page 7 All Products limited to Vehicle Tow Rating, see Vehicle Owners Manual. See www.huskytow.com for Warranty Information / Tech Support / Product Updates. ©2017 DTS Mfg. All Rights Reserved. April 4, 2017-Rev14 Page 7 of 8...
- Page 8 Husky Towing Products and DTS Mfg. with proof of purchase by the original purchaser. The original purchaser shall pay all transportation and shipping costs associated with the return of the defective product and the defective product shall become the property of DTS Mfg.
