9.1.3.

Quick Freeze

Pushing the 3 and 10 buttons on the
display control will activate the quick
freeze. Both compartments start being
cooled quickly.
This function is terminated when the
fridge compartment set value is
changed.
If switched to vacation mode while the
function is active, function is cancelled
Cooling components runs according to
the following cut-in/cut-out values when
the function is active:
Quick freeze

10. ELECTRONIC AND CONTROL SYSTEM

10.1. List of Components and Operation Principles
1) 4151231100
2) 4365121600
3) 4385620385
4) 4919820300
5) 4935320300
6) 5736820300
7) 5747850200
8) 4938825410
9) 5733280100
10) 5712491200
11) 5744020200
12) 4921541000
13) 4941850100
AG2014 70 CM REFRIGERATORS
Freezer Freezer
Cut-Out Cut-In (Air)
(Air)
-30° C/ -21,5° C/
86F 70.7F
KMP_VCC_VEMC9C_R600_115-60_EMBRACO
SEBEKE_INVERTER GR_VEMC9C_UL_SKZ
DUAL THERMAL FUSE GR_72° C_MLX_180mm
DUAL THERMAL FUSE GR_INCH_DAR_MLX_220
DC_FAN_MOTOR_GR_115MM_G84_DC
FRZ_DRAIN ISITICISI_D70_120V_32W_UL
FF TAHLIYE ISITICISI K70 UL
KART GR U2 K70 SD JTB UL
REED_SENSOR_BOARD
LED_AYD_KARTI_UZUN_HUALIAN
EVAPORATOR ISITICISI_K70520
LED2TO6HW-G_2013_SSC_DISPLAY_BOARD_GR
LED2TO6HW_BYG2014_DISPLAY_BOARD_GR
00
