Extech Instruments 380560 User Manual page 4

Specifications
General Specifications
Range Specifications
Note: Specifications based on RF Field Strength <3V/m and frequency <30MHz
International Symbols
Find Quality Products Online at:
Circuit Custom one-chip LSI microprocessor circuit
Display 20 mm (0.8") 2000 Count LED Display
Connection type 4-Terminal Kelvin
Measurement ranges Seven ranges (see listing below)
Test voltage 5V DC
Comparator Built-in HI/LO/GO testing with audible beeper
Measurement speed Resistance 1 second, comparator mode 0.5 seconds
Zero adjust Automatic (no adjustment necessary)
Over-range indication Display reads "1____" when the reading is out of range
Operating Temperature 0°C to 50°C (32°F to 122°F)
Operating Humidity Max. 80% RH
Power Supply 110V (380560) or 220V (380562) ±15%, 50/60Hz
Weight 2.2kg (4.85 lbs)
Dimensions 280 x 210 x 90mm (11 x 8.3 x 3.5")
Replacement Kelvin leads 380465
Range Resolution
20 mΩ 0.01mΩ
200 mΩ 0.1mΩ
2 Ω
.001Ω
20 Ω
.01Ω
200 Ω 0.1 Ω
2K Ω
.001kΩ
20K Ω
.01kΩ
GlobalTestSupply
www.
Test Current Accuracy (%rdg)
1A ± (0.2% + 6 digits)
1A
0.1A
10mA
± (0.2% + 4 digits)
1mA
0.1mA
10uA
4
Test Voltage
2.7V DC
3.3V DC
3.5V DC
4.1V DC
4.5V DC
380560-en-GB_V1.9 2/17
