Cooling; Cooling System/Coolant; Connection Diagram - Coolant Hoses - Volkswagen CC 2012 Workshop Manual

CC 2012 ➤ , Passat 2011 ➤ , Passat Variant 2011 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 06.2019
19 –

Cooling

1

Cooling system/coolant

⇒ "1.1 Connection diagram - coolant hoses", page 138
⇒ "1.2 Checking cooling system for leaks", page 140
⇒ "1.3 Draining and adding coolant", page 142
1.1

Connection diagram - coolant hoses

Note
Incorporation of auxiliary heater in ⇒ auxiliary heater; Rep. gr.
♦
82 coolant circuit.
Secure all hose connections with the correct type of hose clips
♦
(same as original equipment) ⇒ Electronic parts catalogue .
Hose clip pliers - VAS 6340- or hose clip pliers - VAS 6362-
♦
are recommended for installation of spring-type clips.
The arrow markings on coolant pipes and on ends of hoses
♦
must align when installing.
138
Rep. gr.19 - Cooling
