OpenEye OE-C3011D4 Quick Start Manual

CONNECTIONS
1
4
1 1 RJ-45 RJ-45 - - For network and PoE connections For network and PoE connections
1 1 12vDC + 12vDC +
2 2 Power (12vDC) Power (12vDC)
2 2 GND - GND -
To restore the camera to factory defaults: To restore the camera to factory defaults:
1. Disconnect power for 30 seconds. 1. Disconnect power for 30 seconds.
3 3 Reset Button Reset Button - -
2. Reconnect power and wait 30 seconds. 2. Reconnect power and wait 30 seconds.
3. Press and hold the reset button for 20 seconds. 3. Press and hold the reset button for 20 seconds.
1 1 Alarm Out - Alarm Out -
2 2 Alarm Out + Alarm Out +
3 3 GND GND
4 4 Alarm In Alarm In
4 4 Alarm & Audio I / O Alarm & Audio I / O
5 5 GND GND
6 6 Audio In Audio In
7 7 GND GND
8 8 Audio Out Audio Out
Supports up to 512GB microSD card for Edge storage. Supports up to 512GB microSD card for Edge storage.
5 5 microSD Card Slot microSD Card Slot - -
Do not add or remove the microSD card when the camera is powered on. Do not add or remove the microSD card when the camera is powered on.
Liberty Lake, WA, USA
509.232.5261
openeye.net
3
5
2
Power Connection Power Connection
Alarm connection Alarm connection
Ground connection Ground connection
Alarm connection Alarm connection
Ground connection Ground connection
Two-way audio transmission Two-way audio transmission
Ground Connection Ground Connection
Two-way audio transmission Two-way audio transmission
Copyright ©2020 OpenEye.
All Rights Reserved. Information contained in this document is
subject to change without prior notice. OpenEye does its best to
provide accurate information but cannot be held responsible for
typos or mistakes.
This quick start guide provides only basic information on the camera's settings and
operation for initial installation. Please read the user manual for optimal camera
confi gurations.
37552AA
QUICK START GUIDE
OE-C3011D4
4MP | Indoor | Mini Dome
