3. Disconnect and
remove the Battery
Pod - see page 15,
step 1 - 10.
4. Unscrew the twelve
Grille screws as
shown in
fig.20
to
remove the Inner
Beware of
Nozzle and Propeller
sharp corners
Nozzle.
when servicing
5. While
holding
the
Propeller, use an M6
socket
wrench
to
remove the nut from
the Propeller shaft as shown in
6. Slide the Propeller off the shaft, taking care not to lose
the drive pin or washers.
7. Remove the blockage from the Propeller or Propeller
Shaft.
8. Replace the drive pin (if removed),
Propeller. Turn the Propeller slowly until you locate the
pin and push the Propeller fully on.
22
Fig.21
fig.21.
see
fig.22, and
Drive Pin In Position
Fig.22
9. Replace the washer and nut and tighten with the
socket wrench while holding the Propeller, make sure it
is securely fastened.
(see fig.23)
Propeller Shaft
10. Replace the Front Grille and Propeller Nozzle.
11. Install the Battery Pod and replace the Nose Cone
when ready for use.
Sand or Grit on O-ring Seal
Ensure that sand/grit does not get on the seals as Correct
maintenance and care is essential. To remove sand or grit
from the O-ring Seal, rinse the O-ring Seals in fresh water
and apply fresh lubricant. If there is sand inside the Battery
Housing, gently brush the sand from the unit, take care not
to scratch the sealing surfaces.
If an O-ring Seal is damaged, replace it with a new one
(see fig.1, item18) and apply fresh lubricant before use.
23
Propeller
Drive pin
Washer
Nut
Fig.23
