- Page 1 ATMOS 1000 Pipette Accuracy Tester instrument P20 – P1000 Operation Manual Rev. 1.05 Designed in Switzerland Assembled in Switzerland UniPix, Switzerland Web: www.unipix-lab.com Email: info@unipix-lab.com UniPix Atmos ATMOS 1000 Operation manual Rev. 1.05 page 1/1...
-
Page 2: Installation
It is recommended to verify that the instrument battery is well charged or use the instrument Function with the external power supply connected via the USB cable. The UniPix Atmos Pipette Accuracy Tester is an instrument for precise measurement air The instrument is powered by an internal Li-ion displacement pipette, without need of liquid. It is... - Page 3 The arrow "ID" at the bottom right of the screen allows to enter date and pipette ID for USB transfer • 100% of nominal volume of calibration data (see "interfacing" section). • 50% of nominal volume • 10% of nominal volume The screenshot below shows example of the volume selection display for the P1000 pipette. Note: pressing the arrow at the bottom left of the screen returns to the previous menu. Should you desire to measure another volume than indicated, this is feasible but will prevent automated statistic computation. UniPix Atmos ATMOS 1000 Operation manual Rev. 1.05 page 3/6...
- Page 4 The pipette and the piston should not move during the measurement. The measurement time is typically five seconds. Continue 2: Release phase: On the display of this new screen, release the piston, but don’t remove the tip. The reasons for bad reading can be: Release • Bad insertion of the tip into the port • User not following instructions during the calibration process • A totally nonfunctional pipette • A very leaky pipette or tip connection UniPix Atmos ATMOS 1000 Operation manual Rev. 1.05 page 4/6...
- Page 5 (a) (b) P1000 ± 8 µl ± 3 µl P200 ± 1.6 µl ± 0.6 µl P100 ± 0.8 µl ± 0.3 µl P20 ± 0.2 µl ± 0.1 µl (a) Expressed as the deviation of the mean of a tenfold measurement from selected volume (b) Expressed as the coefficient of variation of a tenfold measurement UniPix Atmos ATMOS 1000 Operation manual Rev. 1.05 page 5/6...
-
Page 6: Maintenance
Help command: this will send the list of all damage, the join can be replaced by the user. available commands Please carefully follow these instructions: • Before changing the joint, order the The second set of commands is for remote original replacement part from UniPix web controlling Atmos for operation in a robotic site platform : • Unscrew the port After receiving this command, Atmos will • Remove the elastomer joint which is inside start a calibration measurement sequence •... -
Page 7: Specifications
P 200 200 µl ±0.25µl 100 µl ±0.25µl Warranty 20 µl ±0.25µl UniPix shall not be retained liable for any P100 100 µl ±0.15µl consequences of improper handling, use, servicing, operating or unauthorized repairs of the 50 µl ±0.15µl instrument or the consequences of normal wear and tear as well as the failure to follow the 10 µl...
