- Page 1 32-bit Microcontrollers DEMOEM Lab Tutorial V1 ColdFire MCU for smart metering...
- Page 2 DEMOEM Lab Tutorial: V1 ColdFire MCU for smart metering Introduction voltage and current waveforms. c. Disconnect and reconnect the USB cable from the DEMOEM board. Step by Step Instructions These labs highlight key features of the MCF51EM d. Toggle power switch K6 to power-down, then power-up microcontroller and are implemented as a standard Press SW1 until you see the “Measurement”...
- Page 3 DEMOEM Lab Tutorial: V1 ColdFire MCU for smart metering Clear the log of all entries by tapping either (SW2 + SW3) Step by Step Instructions State or (SW2 + SW4) simultaneously. When the log is cleared, Press SW1 until you see the IRTC Calendar state on the a message will be displayed on the LCD as follows: display, with the following syntax: dDD-MM-YY, where d...
- Page 4 Get to know the DEMOEM Power IR Comm switch port Barrel connector for external power Custom LCD glass LEDs Push buttons for USB for demo menu embedded navigation Optional RS232 serial interface 9S08QE8 signal generator circuit for three-phase Daughter card emulation adapter for 80- or 100-pin MCU...
