User Manual Modbus Slave / HART Master
Document code: MN67908_ENG Revision 1.001 Page 20 of 32
Industrial Electronic Devices
In the field "Params" the parameters for the commands are defined;
In the field "Position" the starting byte of the internal array where mapping the HART data is defined;
In the field "Swap" the bytes' order is reversed;
In the field "Conv Int" the data from HART device is converted in Integer format;
In the field "Operations" a post-operation on the data read is defined;
In the field "Mnemonic" a description of the variable is defined.
Note:
In order to configure the HART devices and their variables, it is possible to scan the HART network and get the data automatically. It
is enough to click on "Scan" button. See page 22 for more info.
