Industrial Electronic Devices
CHARACTERISTICS:
The Configurable CANopen / PROFIBUS Slave - Converter allows the following characteristics:
Two-directional information between CANopen network and PROFIBUS;
Eletrical isolation between two buses;
Up to 244 bytes in reading and 244 bytes in writing on PROFIBUS;
Power Supply 8...19V AC or 12...35V DC;
Mountable on 35mm Rail DIN;
CANopen Client;
CANopen Server;
PDO Producer and Consumer;
Temperature range -40°C to 85°C.
CONFIGURATION:
You need Compositor SW67551 software on your PC in order to perform the following:
Define the parameter of the CANopen;
Define the parameter of the PROFIBUS;
Define SDO Server informations;
Define SDO Client informations;
Define PDO informations (RPDO/TPDO);
Define NodeGuarding informations;
Transmit CANopen frames;
Create a GSD File;
Update the device.
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual CANopen / PROFIBUS Slave
Document code: MN67551_ENG
Revision 1.100
INFO:
www.adfweb.com
Page 6 of 38
Phone +39.0438.30.91.31
