The means of the fields for "PROFIBUS" are:
In the field "ID Dev." the address for the PROFIBUS side is defined;
In the field "N Byte IN" the number of byte from the master PROFIBUS to the gateway is defined;
In the field "N Byte OUT" the number of byte from the gateway to the master PROFIBUS is defined;
If the field "Create GSD file from PDO
inserted in a Module, otherwise a Module contains up to 64 byte;
If the field "Enable SDO
In the field "Index SDO for change
The meaning of the fields of "Ethernet" are:
In the field "IP Address" the IP address to assign to the converter is defined;
In the field "SubNet Mask" the SubNet Mask of the converter is defined;
In the field "Default Gateway" the default gateway of the network is defined. This feature can be enabled or disabled pressing the
Check Box field. This feature is used for going out of the net.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Map" is checked when you create the "GSD File" every PDO mapped in "Set PDO Access" is
Command" is checked, it is possible to change the address of PROFIBUS through CANopen SDO object;
ID" the index of the SDO used to change the address of PROFIBUS is defined.
