10.1.5 Connection to the cooling system

•
•
•
•
The connection to the cooling system can occur as closed or open cooling circuit. The
connection to a closed cycle cooling circuit is recommended, because the danger of
contamination of coolant is very small. Preferably also a monitoring of the pH value of
the coolant should be installed.
Pay attention to a corresponding conductor cross-section at required equipotential
bonding in order to avoid electro-chemical procedures.
Other elements in the cooling circuit such as pumps, mixing valves, shut-off valves, ven-
tilation etc. must be attached according to the cooling system and the local conditions.
NOTICE
10 20
-25 -45 -40
-20
-42 -36
-15 -37 -31
-10 -34 -26
-5
-29 -22
0 -26 -19
5 -23 -15
10
-19 -11
15 -18 -7
20 -12 -4
25
-8 0
30 -6 3
35 -2 8
40
1 11
45 4 15
50 8 19
Screw in the connecting ducts according to installation instructions for fitting
0000650-G14K.
he connection to the coolant must be carried out with flexible, pressure-resistant
hoses and secured with clamps.
Pay attention to flux direction and check tightness !
The cooling flow must always be started before starting the COMBIVERT.
A discontinuous mode is not recommended, since this leads to a reduc-
tion of the service life.
