Summary of Contents for DR. Z Amplification Signature Series
- Page 1 Z-Master Manual Model: ZA-47 www.drzamps.com...
- Page 2 This symbol warns the user of dangerous voltage levels localized within the enclosure. This symbol advises the user to read all accompanying literature for safely operating the unit Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions.
- Page 3 As the first “signature series” amp in Dr. Z history, the Z-Master exhibits a wholly uncanny voice not unlike the man himself, Joe Walsh.
- Page 4 Front Panel: 1. Input: Input jack for your guitar. 2. Vol 1: Controls overall gain of the “bright” channel. This volume will have a brighter, less bass-heavy sound, great for tightening up humbucker guitars. It is internally jumpered with the Vol 2 control so that you can finely tune the amount of brightness into the “normal”...
- Page 5 MODEL: ___________________ SERIAL NUMBER: ___________ INPUT VOLTAGE: ____________ MADE IN USA...
- Page 6 EC/EU Declaration of Conformity Document: CE – ZA-47 Manufacturer: Dr. Z Ampli cation 17011 Broadway Ave. Maple Heights, OH 44137 -3407 We declare that the designated product (s) DR. Z Z-Master is/are in conformity with the European Directives: 2014/30/EU EMC Directive of 26 February 2014 20 11/65/EU RoHS Directive of 8 June 2011 2014/35/EU...
