Zhone IPD 12000E Datasheet

DSL the Easy Way™
provides true 'Plug &
Play', loop-bonded
operation with no
configuration required
High density system with
12 line card slots (up to
576 lines / chassis or 1,152
lines per 7' rack)
High bandwidth, full
duplex 16-GigE uplink and
24-GigE backplane
capacities
Supports T1, E1, ADSL2+,
SHDSL/SHDSL.bis, and

Active Ethernet,

hot-swappable, access
modules with loop
bonding capabilities
Video Ready, High-capacity Ethernet-based Modular Multi-Service Broadband Loop Carrier for large scale Central Office DSL deployments
Survivable network
topology options based
on RFC3619 EAPS rings
and uplink card
redundancy
Zhone's IPD12000E Broadband Loop Carrier (BLC) provides a high capacity, native IP Ethernet platform for the feature rich multi-service access multiplexer modules in the IPD family.
Metro Ethernet Forum
The IPD12000E is engineered for efficient, high-speed IP data transport in a compact, fault-tolerant chassis. Supporting high-density Active Ethernet, ADSL2+, SHDSL, extended-rate SHDSL.bis, and T1/E1 access modules, the Ethernet-based IPD12000E is the optimal line
(MEF 9/14) Certified for
aggregation platform for today's advanced IP-based access networks. Incumbents, Competitive Operators, and Internet Service Providers are able to cost-effectively offer the full range of today's advanced IP-based services, such as high-speed broadband Internet and IP
video. Most importantly, these services can be delivered over a pure IP network without a dependency on ATM.
EVPL and E-LAN Services
The IPD12000E features a high capacity backplane, delivering up to 2 Gbps throughput to each of the 12 access slots, and up to 16 Gbps upstream from a pair of Broadband Services Switch 8000 uplink cards. Dual 50-pin, RJ-21 connectors are provided for every slot so
that the chassis can support higher port density modules in any access slot. High port density modules include a 48-port ADSL2+, a 48-port SHDSL.bis, and 24-port, 4-wire T1 and E1 modules. For mission-critical, high speed data applications, the IPD12000E offers
survivable network topologies by means of Ethernet Automatic Protection Switching (EAPS) rings and BSX8000 uplink card-level redundancy options.
New (optional) enhanced
Managing all of these high-speed services could not be simpler with the availability of a full range of local and remote management options, including an integrated Web GUI, SNMP, and Command Line Interface (CLI). All of the Access Modules offer simple, 'Plug & Play'
operation, with the system configuring each port automatically and without intervention. When more sophisticated bandwidth management functionality is desired, the IPD supports Zhone's complete Multi-media Traffic Management (MTM) feature set, giving system
fan tray with more robust,
operators the ability to prioritize traffic based on DSCP, IP address ranges, MAC address ranges, and VLAN ranges. Rate limiting features and 802.1p priority also ensure that specific applications are given appropriate priority and bandwidth allocation throughout the
system, while marking packets for appropriate VLAN and QoS management by upstream network devices.
fault tolerant controller
The IPD12000E supports up to two BSX8000-5 (Broadband Switch Modules ) uplink cards, each operating in simplex mode or a pair of BSX8000-5R cards operating in redundant mode. Each BSX8000 switch card supports four (4) Gigabit uplink ports, and has provisions
for an optional MIM (Micro Interface Module), allowing the IPD to integrate easily into a variety of network designs. A variety of MIM types are available, including: 10/100 Ethernet; 100 Mbps fiber; 2 x T1/E1; 4 x T1/E1; and either 2- or 4- Gigabit Ethernet ports using
design and greater / more
either copper or fiber Small Form Factor Pluggable modules.
For installation flexibility, the IPD12000E is only 9-rack units high, and has removable mounting brackets that can be placed in increments of 1.45" up to 9.28" from the front of the chassis, allowing for multiple installation options in either 19" or 23" equipment racks.
IPD 12000E Broadband Loop Carrier (BLC)
IPD12000E
uniform airflow capacity
