Flexible ATM or IP Uplinks
End-to-End Management
System
Environmentally
Hardened
Integrated Access +
Transport
TDM, ATM, or IP /
Gigabit-Ethernet
Resilient Packet Ring (RPR)
ADSL2+ / VDSL2 / PON /
Ethernet
Raptor ATM / IP DSLAM
Raptor 319, Raptor 719, Raptor 723
The DSLAM for the New Era in Broadband
Raptor DSLAM delivers the next generation of high-performance business
and residential DSL services. With Raptor, carriers can offer digital video,
high bandwidth Internet access and cell relay services from a single
platform.
Raptor is the only DSLAM a carrier needs for deployment anywhere in
their network. It supports ADSL2+, VDSL2, and SHDSL loops with ATM,
IP and Ethernet uplinks for legacy, overlay and green-field deployments.
Raptor allows carriers to deploy the same chassis in CO and Remote
Terminal sites in both 3-U and 7-U configurations.
Advertisement
Related Manuals for Zhone 4800 EXPRESS 4800 Express
Summary of Contents for Zhone 4800 EXPRESS 4800 Express
- Page 1 Flexible ATM or IP Uplinks End-to-End Management System Environmentally Hardened Integrated Access + Transport TDM, ATM, or IP / Gigabit-Ethernet Resilient Packet Ring (RPR) ADSL2+ / VDSL2 / PON / Ethernet Raptor ATM / IP DSLAM Raptor 319, Raptor 719, Raptor 723 The DSLAM for the New Era in Broadband Raptor DSLAM delivers the next generation of high-performance business and residential DSL services.
- Page 2 Raptor ATM / IP DSLAM Deployed in the Central Office, Remote Terminal, outdoor cabinets or basements, the Raptor is offered in a range of compact, hardened chassis supporting densities up to 960 ports per shelf with integrated packet ring transport. With line cards, cabling, provisioning and management common to all chassis, the Raptor minimizes training, stocking, and operating expenses.
-
Page 3: Technical Specifications
Technical Specifications Dimensions Raptor 319 - Slots: 10; front card access - Dimensions: (3U) 5.22 in. x 17.40 in. x 11.3 in. / 13.26 cm x 44.20 cm x 28.70 cm (HWD) Raptor 719 - Slots: 17; front card access - Dimensions: (7U) 12.22 in. -
Page 4: Ordering Information
Ordering Information Raptor Chassis RAPTOR-CHASSIS-319 RAPTOR-CHASSIS-19 RAPTOR-CHASSIS-23 RAPTOR Uplinks MALC-UPLINK-2-GE MALC-UPLINK-2-GE-ONLY MALC-UPLINK-DS3/E3-ATM/IP MALC-UPLINK-OC3C/STM1-ATM/IP MALC-UP-T1/E1-ATM/TDM/IP-16 MALC-UPLINK-T1/E1-ATM/IP-8 RAPTOR ADSL2+, ReachDSL and VDSL2 Line Cards MALC-ADSL-48A/M MALC-ADSL-48B MALC-ADSL+SPLTR-48A/M-2S MALC-VDSL2-24 MALC-REACHDSL-24 MALC-REACHDSL+SPLTR-24 RAPTOR OLT Line Cards MALC-BPON-SC-1 MALC-GPON-SC-1 MALC-ACTIVE-ETH-10 RAPTOR EFM Line Cards MALC-EFM-T1/E1-24 MALC-EFM-SHDSL-24 RAPTOR SHDSL Line Cards (non-EFM) MALC-G.SHDSL-24...
