Duct Cover Extension Short, Long
Z1C-00LL
Z1C-01LL
For use with Layers Is. and Duo Is. range hood
Mounting the duct cover
Fixation des cheminees
Fijación de las chimeneas
Fissaggio dei camini
Pag. 4
Pag. 6
Pag. 8
Pag. 10
customer service
1.888.880.8368
Advertisement
Related Manuals for Zephyr Duct Cover Extension Z1C-00LL
Summary of Contents for Zephyr Duct Cover Extension Z1C-00LL
- Page 1 Duct Cover Extension Short, Long Z1C-00LL Z1C-01LL For use with Layers Is. and Duo Is. range hood Mounting the duct cover Fixation des cheminees Fijación de las chimeneas Fissaggio dei camini customer service 1.888.880.8368 Pag. 4 Pag. 6 Pag. 8 Pag.
- Page 2 www.zephyronline.com DUCT COVER EXTENSION SPECIFICATION - 2 -...
- Page 3 KIT Z1C-00LL Duct Cover Short KIT Z1C-01LL Duct Cover Long - 3 -...
- Page 4 MOUNTING THE DUCT COVER 1. Remove the (2) screws to unlock the top support frame from the bottom support frame. Fig.1. Adjust the height by referring to the diagram in Fig. 2. Secure the support frames together with (2) screws per extension arm (Tot. 8). Fig.3 2.
- Page 5 - Make 4, holes in the ceiling and drive in (3) screws without completely tighte- ning them. Pay attention not to insert the screw into the hole marked with an X on the hole template Fig.7 6. Lift the hood assembly to the cei- ling and align the top support fra- me with the (3) screws previously installed in the ceiling.
- Page 6 FIXATION DES CHEMINEES 1. Enlevez les (2) vis pour séparer la partie supérieure de la partie in- férieure. Fig. 1. Régler la hauteur désirée en se référant aux cotes indiquées dans la (fi g. 2) et la blo- quer au moyen des (2 ) vis fournies avec l’appareil.
- Page 7 - Eff ectuer les 4 trous au plafond et visser (3) vis sans les serrer comp- lètement et en prenant garde de ne pas insérer la vis dans le trou marqué par un X sur le gabarit de forure. Fig. 7 6.
- Page 8 FIJACIÓN DE LAS CHIMENEAS 1. Quite los (2) tornillos para desblo- quear la parte superior de la infe- rior. Fig. 1. Regule la altura deseada refi riéndose a las cuotas indicadas en (fi g.2) y fi jar conlos (2) tornillos incluidos.
- Page 9 - Efectúe los 4 agujeros en el techo y atornille tornillos sin ajustar com- pletamente, asegurándose de no introducir el tornillo en el agujero señalado con una X en laguía de perforación. Fig. 7 6. Eleve la campana hacia el techo y alinee el armazón de soporte supe- rior con los 3 tornillos precedente- mente instalados en dicho techo.
- Page 10 FISSAGGIO DEI CAMINI 1. Togliere le due viti per sbloccare la parte superiore da quella inferiore. Fig. 1. Regolare l’altezza desiderata facendo riferimento alle quote in- dicate in Fig. 2 e bloccarla median- te le (2) viti in dotazione. (Tot. 8) Fig.3 2.
- Page 11 - Eff ettuare i 4 fori al soffi tto ed avvi- tare (3) viti senza tirarle completa- mente facendo attenzione di non inserire la vite nel foro contrasse- gnato con una X sulla dima di fo- ratura. Fig. 7 6. Sollevare la cappa verso il soffi tto ed allineare la struttura superiore con le (3) viti precedentemente in- stallate nel soffi tto stesso.
- Page 12 3FA0173...
