- Page 1 Duct Cover Extension Z1C-00PN For use with Plane range hood Mounting the duct cover Fixation des cheminees Fijación de las chimeneas Fissaggio dei camini customer service 1.888.880.8368 Pag. 3 Pag. 4 Pag. 5 Pag. 6...
- Page 2 www.zephyronline.com DUCT COVER EXTENSION SPECIFICATION - 2 -...
- Page 3 MOUNTING THE DUCT COVER 1. Install the electrical wiring and test hood for functions prior to installing the duct covers. 2. If using hood in air recirculating mode make sure to install the air diverter plate prior to mounting the duct covers. See the manual included with the recirculating kit for more instructions.
- Page 4 FIXATION DES CHEMINEES 1. Installez la connexion électrique et essayez le fonctionnement de la hotte avant d’installer les cheminées. 2. Si vous utilisez la hotte version recyclage, assurez-vous d’installer le déviateur d’air avant d’installer les cheminées. Pour de plus amples instructions, consultez le manuel fourni avec le kit de recyclage.
- Page 5 FIJACIÓN DE LAS CHIMENEAS 1. Realice la conexión eléctrica y pruebe el fun- cionamiento de la campana antes de instalar las chimeneas. 2. Si se utiliza la campana en versión fi ltrante, in- stale el desviador de aire antes del montaje de las chimeneas.
- Page 6 FISSAGGIO DEI CAMINI 1. Installare la connessione elettrica e provare il funzionamento della cappa prima di installare i camini. 2. Se si utilizza la cappa in versione fi ltrante assi- curarsi di installare il deviatore aria prima del montaggio dei camini. Per ulteriori istruzioni, consulta il manuale fornito con il kit fi ltrante.
- Page 7 - 7 -...
- Page 8 3FA0166...
