Summary of Contents for Zenoah LRTZ2600
- Page 1 OWNER’S MANUAL LRTZ2600 848A2N93A1 (704) LONG REACH TRIMMER LRTZ2600 GB-1...
- Page 2 1-9, Minamidai, Kawagoe, Saitama, Japan DIRECTIVE 89/336/EEC, 98/37/EC 2000 / 14 / EC Internal control production. The products referred are : DESIGNATION : HEDGE TRIMMER MODELS : LRTZ2600 SERIAL NUMBERS : 50100001 and up : Specification sheet : Inspection standard 1st April 2007...
-
Page 3: Table Of Contents
4. Symbols on the machine ... 4 5. For safe operation ... 5 6. Set up ... 8 7. Fuel ... 9 8. Operation ... 10 9. Maintenance ... 12 10. Storage ... 14 11. Disposal ... 14 12. Troubleshooting guide ... 15 LRTZ2600 GB-3... -
Page 4: Specifications
2300 x 400 x 365 Air-cooled 2-stroke gasoline Zenoah GZ25N 1.2Hp (0.9kW) at 7500min 3000± 200min Mixture (Gasoline 50 : Oil 1) (when using ZENOAH genuine oil) Walbro Diaphragm type Centrifugal clutch, Spiral bevel gear, Cam crank 4. Symbols on the machine For safe operation and maintenance, symbols are carved in relief on the machine. -
Page 5: For Safe Operation
2. Never use the product, a. when the ground is slippery or when you can’t maintain a steady posture. LRTZ2600 b. At night, at times of heavy fog, or at any other times when your field of vision might be... - Page 6 If it continues to move even after the throttle has been moved fully back, turn off the engine and take the unit to your authorized ZENOAH ser- vicing dealer for repair. USING THE PRODUCT IMPORTANT Cut only materials recommended by the manufacturer.
- Page 7 LRTZ2600 HANDLING FUEL 1. The engine of the ZENOAH prod- uct is designed to run on a mixed fuel, which contains highly flam- mable gasoline. Never store cans of fuel or refill the tank of the unit...
-
Page 8: Set Up
LRTZ2600 6. Set up MOUNTING ENGINE 1. Push the drive shaft housing toward the clutch hous- ing and move it by hand to check that the drive shaft is engaged with the gears. 2. Insert the drive shaft housing into the clutch housing until it bottoms, and align the positioning holes on the clutch housing and the shaft tube and install the screw. -
Page 9: Fuel
• The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle engine use (JASO FC GRADE OIL or ISO EGC GRADE). -
Page 10: Throttle Lever
LRTZ2600 8. Operation STARTING ENGINE WARNING The cutting head will start moving upon the engine starts. 1. Rest the unit on a flat, firm place. Keep the cutting head off the ground and clear of surrounding objects as it will start moving upon starting of the engine. - Page 11 2. Turn the bolt located on the top of the trimming mecha- nism counter-clockwise to loosen it. 3. Adjust the angle of the blades to the desired angle, and then fix the bolt firmly back into place. (1) Clamp bolt (2) Trimming mechanism (3) Tighten (4) Loosen LRTZ2600 GB-11...
-
Page 12: Spark Arrester
• If the blades become so worn down that it is no longer possible to eliminate the gap between them, you should contact the authorized ZENOAH servicing dealer from which you purchased your ZENOAH trim- mer to have the blades resharpened or replaced. GEAR CASE •... - Page 13 SPARK ARRESTER • The muffler is equipped with a spark arrester to pre- vent red hot carbon from flying out of the exhaust out- let. Periodically inspect and clean as necessary with a wire brush. Spark arrester LRTZ2600 GB-13...
-
Page 14: Storage
LRTZ2600 9. Maintenance INTAKE AIR COOLING VENT WARNING • Never touch the cylinder, muffler, or spark plugs with your bare hands immediately after stopping the engine. The engine can become very hot when in operation, and doing so could result in severe burns. -
Page 15: Troubleshooting Guide
(exhaust port) → carbon is built-up air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
