HB2302
HBZ2601
OWNER'S MANUAL
BLOWERS
HB2302 / HBZ2601
848L0B93A2 (704)
GB-1
G
G
B
B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HBZ2601 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zenoah HBZ2601

Summary of Contents for Zenoah HBZ2601

  • Page 1 HB2302 HBZ2601 848L0B93A2 (704) OWNER’S MANUAL BLOWERS HB2302 / HBZ2601 GB-1...

  • Page 2: Explanation Of Symbols And Safety Warnings

    HB2302 / HBZ2601 EXPLANATION OF SYMBOLS AND SAFETY WARNINGS MODEL HB2302 22.5cm HBZ2601 25.4cm APPROVAL NUMBER OF CE EXHAUST EMISSION REGULATION (2002/88/EC) GB-2 ZENOAH CO., LTD WARNING!!! RISK OF DAMAGING HEARING Wear head, eye and ear protection. SOUND LEVEL ISO 11094...

  • Page 3: Table Of Contents

    6. Set up ... 8 7. Fuel ... 9 8. Operation ... 10 9. Maintenance ... 11 10. Storage ... 13 11. Disposal ... 13 12. Optional vacuum kit usage ... 14 13. Troubleshooting guide ... 16 HB2302 / HBZ2601 GB-3...

  • Page 4: Specifications

    HB2302 / HBZ2601 2. Specification Model Dimensions (LxWxH) Dry weight (w/o tube and nozzle) kg Fuel tank capacity Engine Type Displacement Carburetor Ignition system Spark plug Muffler Operating Engine Speed Idle speed Average Air Volume Max. Air Velocity Noise Level at 50 feet Specifications are subject to change without notice.

  • Page 5: For Safe Operation

    (Raynaud’s phenomenon), which symptoms are tingling and burning sensa- HB2302 / HBZ2601 tions followed by loss of color and numbness in the fingers. All factors which contribute to...

  • Page 6: Working Plan

    HB2302 / HBZ2601 5. For safe operation 1. Operate power equipment only at reasonable hours-not early in the morning or late at night when people might be disturbed. Com- ply with times listed in local ordi- nances. 2. To reduce sound levels, limit the number of pieces of equipment used at any one time.
  • Page 7 Zenoah products or products which have been cer- tified by Zenoah for use with the Zenoah product. 6. In the event that any part must be replaced or any maintenance or...

  • Page 8: Set Up

    HB2302 / HBZ2601 6. Set up BLOWER PIPE • Align groove in blower pipe with projection on blower housing (or another blower pipe) and slide the pipe onto the blower housing (or another blower pipe). Rotate the pipe clockwise to lock it into place.

  • Page 9: Fuel

    • The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle en- gine use (JASO FC GRADE OIL or ISO EGC GRADE).

  • Page 10: Operation

    HB2302 / HBZ2601 8. Operation STARTING ENGINE 1. Rest the unit on a flat, firm place. 2. Pump the primer until fuel flows out in the clear tube. 3. Move the choke lever upward to close the choke. 4. Holding the blower handle, pull the starter rope with your right hand.

  • Page 11: Maintenance

    After cleaning, air dry the element com- pletely. 3. Reinstall the filter. Never forget to attach the screen. If the screen is not attached, the cleaner will not seal properly and the dusts come into the cylinder. HB2302 / HBZ2601 Every Every Every 25 hours...
  • Page 12 REPLACEMENT PLUG HB2302 : CHAMPION RCJ6Y HBZ2601 : NGK CMR7A IMPORTANT • Note that using any spark plugs other than those des- ignated may result in the engine failing to operate properly or in the engine becoming overheated and damaged.

  • Page 13: Storage

    3. Store unit in a dry, dust free place, out of the reach of children. (Air inlet net) 11. Disposal When disposing your machine, fuel or oil for the machine, be sure to allow your local regulations. HB2302 / HBZ2601 GB-13...

  • Page 14: Optional Vacuum Kit Usage

    HB2302 / HBZ2601 12. Optional vacuum kit usage Attach the adequate accessories, respectively for blower operation and dust-collecting op- eration. NOTE • Use the gloves during operation. • In adjustment of the blower/dust collector or in other types of operation, be sure to stop the engine and detach the spark plug cap.

  • Page 15: Dust Collecting Operation

    Keep work area clear of other per-sons and pets. Risk of long hair being drawn into air inlet. Wear head, eye, and hearing protection when op erating this equipment. Do not run unit while vacuum door is unsecured. HB2302 / HBZ2601 GB-15...

  • Page 16: Troubleshooting Guide

    (exhaust port) → carbon is built-up air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
