Zenoah Water Pump PE2300 Owner's Manual

Zenoah water pump owner's manual
Hide thumbs

Advertisement

PE2300
OWNER'S MANUAL
WATER PUMP
PE2300
848AB193A0 (705)
GB-1
G
G
B
B

Advertisement

Table of Contents
loading

  Related Manuals for Zenoah Water Pump PE2300

  Summary of Contents for Zenoah Water Pump PE2300

  • Page 1 PE2300 848AB193A0 (705) OWNER’S MANUAL WATER PUMP PE2300 GB-1...
  • Page 2: Table Of Contents

    SAFETY PRECAUTIONS Warning labels bearing the mark on the product and in this Manual refer to important safety matters. Please familiarize your- self with them and observe them well. If a warning label on the product becomes soiled or detached, please order a replacement label from your dealer and attach it in the requisite place.
  • Page 3: Specification

    (mm) Suction (L/min) Single-cylinder air-cooled 2-cycle gasoline engine (cc) Gasoline 50 : Oil 1 (when using ZENOAH genuine oil) Electronic controlled flywheel magnet type 1 plug wrench, 1 Strainer, 2 hose coupling, 3 clump PUMP PERFORMANCE CURVE Diacharge (L/min.) 4. Symbols on the machine For safe operation and maintenance, symbols are carved in relief on the machine.
  • Page 4: For Safe Operation

    5. For safe operation Before using this product, please read this Operator's Manual thoroughly to ensure correct operation. The fol- lowing are precautions that should be observed in order to use the product smoothly. Elsewhere in the Manual, warning mark is used to bring your attention to these precautions.
  • Page 5 Manual. When maintenance or parts replacement not indicated in this Manual are required, please con- sult your product supplier or nearest ZENOAH prod- uct dealer. • Never keep the engine running while carrying out in- spections or maintenance.
  • Page 6: Set Up

    • The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle en- gine use (JASO FC GRADE OIL or ISO EGC GRADE).
  • Page 7: Operation

    7. Fuel 5. Put a clear indication on the outside of the container to avoid mixing up with gasoline or other containers. 6. Indicate the contents on outside of container for easy identification. ■ FUELING THE UNIT 1. Untwist and remove the fuel cap. Rest the cap on a dustless place.
  • Page 8 8. Operation 1. Press the primer at the bottom of the carburetor a few times with your finger until the fuel starts to flow through the transparent pipe. NOTE • There is no need to operate the primer when restart- ing immediately after stopping the engine, provided there is fuel left in the fuel tank.
  • Page 9: Maintenance

    Con- tact with hot muffler may result in a personal injury. • Do not modify the pump or dismantle the engine. • When replacing parts please use Zenoah original parts or designated parts. ■ Air cleaner •...
  • Page 10 9. Maintenance • When replacing plugs, please use designated items. CHAMPION CJ-6Y IMPORTANT • If too much fuel is absorbed or poor quality oil is used, the spark plug electrodes become dirty, making the engine harder to start. • Note that using any spark plug other than those des- ignated may result in the engine failing to operate properly or in the engine becoming overheated and damaged.
  • Page 11: Storage

    9. Maintenance INTAKE AIR COOLING VENT WARNING • Never touch the cylinder, muffler, or spark plugs with your bare hands immediately after stopping the en- gine. The engine can become very hot when in op- eration, and doing so could result in severe burns. •...
  • Page 12: Troubleshooting Guide

    Case 5. Water leakage from pump CHECK bolts When your unit seems to need further service, please consult with our ZENOAH service shop in your area. GB-12 PROBABLE CAUSES → incorrect fuel → drain it and use correct fuel →...
  • Page 13: Limited Warranty

    30 days if used for rental purpose) from the date of initial purchase. THE PURCHASER SHALL BEAR COSTS OF TRANS- PORTING THE UNIT TO AND FROM THE ZENOAH DEALER. THE PURCHASER SHALL NOT BE CHARGED FOR DIAG- NOSTIC LABOR WHICH LEADS TO THE DETERMINATION THAT A WARRANTED PART IS DEFECTIVE, IF THE DIAG- NOSTIC WORK IS PERFORMED AT THE ZENOAH DEALER.
