BK2650DL
OWNER'S MANUAL
BRUSHCUTTERS
BK2650DL
848EG093A0 (406)
G
G
B
B
GB-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BK2650DL and is the answer not in the manual?

Questions and answers

Summary of Contents for Zenoah BK2650DL

  • Page 1 BK2650DL OWNER’S MANUAL BRUSHCUTTERS BK2650DL 848EG093A0 (406) GB-1...
  • Page 2: Explanation Of Symbols And Safety Warnings

    BK2650DL EXPLANATION OF SYMBOLS AND SAFETY WARNINGS MAY INVOLVE A DAILY LEVEL OF PERSONAL EXPOSURE TO NOISE FOR THE OPERATOR EQUAL TO OR GREATER THAN MODEL BK2650DL 25.4 cm GB-2 WARNING!!! RISK OF DAMAGING HEARING IN NORMAL CONDITIONS OF USE, THIS MACHINE...
  • Page 3: Table Of Contents

    4. Symbols on the machine ... 4 5. For safe operation ... 5 6. Set up ... 8 7. Fuel ... 9 8. Operation ... 10 9. Maintenance ... 13 10. Storage ... 15 11. Troubleshooting guide ... 16 BK2650DL GB-3...
  • Page 4: Specifications

    BK2650DL 2. Specification Model Overall size (LxWxH) Dry weight Engine Model Displacement Fuel Carburetor Ignition system Spark plug Fuel tank capacity Starter Clutch Reduction ratio Cutting head rotating direction Specifications are subject to change without notice. 3. Warning labels on the machine Read owner’s manual before oper-...
  • Page 5: For Safe Operation

    2. Never use the product, a. when the ground is slippery or when you can’t maintain a steady posture. BK2650DL b. At night, at times of heavy fog, or at any other times when your field of vision might be...
  • Page 6 If it continues to rotate even after the throttle has been moved fully back, turn off the engine and take the unit to your authorized KOMATSU ZENOAH servicing dealer for re- pair. USING THE PRODUCT IMPORTANT Cut only materials recommended by the manufacturer.
  • Page 7: If Someone Comes

    KOMATSU ZENOAH prod- ucts or products which have been certified by KOMATSU ZENOAH for use with the KOMATSU ZENOAH product. 4. In the event that any part must be replaced or any maintenance or...
  • Page 8: Set Up

    • Stop tightening the screws when the gap A be- comes zero. CE label CONNECTING THE FLEXIBLE SHAFT AND BK2650DL 1. Remove the retaining bolt (M5 x 10) at the center of the joint end and loosen the fixing bolt (M5 x 20).
  • Page 9: Fuel

    3 m (10 ft) away from the fueling point before starting the engine. • The Komatsu Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Komatsu Zenoah oil is not available,...
  • Page 10: Operation

    BK2650DL 8. Operation STARTING A COOLED ENGINE 1. Set the ignition switch to the RUN position. 2. Release the throttle lever. This lever cannot be oper- ated unless you hold the grip firmly and push the up- per lever as far as it goes.
  • Page 11: Stopping Engine

    2. When the cutting head keeps rotating after releasing the trigger, turn the adjusting screw counter-clockwise. Rope guide (1) Idle adjusting screw (cross screw) NOTE • Warm up the engine before adjusting the idling speed. BK2650DL (1) Cable adjuster (2) 0.04in (1-2mm) GB-11...
  • Page 12: Cutting Work

    BK2650DL 8. Operation PUTTING ON THE UNIT NOTE • When carrying the unit on the back, make sure that the throttle lever is set to the idling position and that the throttle wire will not become twisted and tensioned. 1. After confirming that there is no person or obstacle...
  • Page 13: Maintenance

    BK2650DL Note after after replace, if necessary replace carburetor if necessary GAP: .025 in (0.6-0.7 mm) replace, if necessary not adjusting screws...
  • Page 14 (2) Flexible liner (3) Gear case 2. Pull out the inner shaft from the clutch housing side hole, apply Zenoah Guine Power Grease (Z3180- 91250) or lithium-based heat-resistant grease (#2) to the shaft, and insert the shaft back into the liner.
  • Page 15: Intake Air Cooling Vent

    Aged fuel is one of major causes of engine starting fail- ure. Before storing the unit, empty the fuel tank and run the engine until it uses all the fuel left in the fuel line and the carburetor. Store the unit indoor taking necessary measures for rust prevention. BK2650DL GB-15...
  • Page 16: Troubleshooting Guide

    (exhaust port) air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our KOMATSU ZENOAH Limited warranty Should any failure occur on the product under normal oper- ating conditions within the applicable warranty period, the failed part will be replaced or repaired free of charge by a ®...
