OWNER'S MANUAL
BRUSHCUTTERS
BC4310FW
Caution
• Before using our brushcutter, please
read this manual carefully to understand
the proper use of your unit.
• Keep this manual handy.
848JJ393A2 (708)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BC4310FW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zenoah BC4310FW

Summary of Contents for Zenoah BC4310FW

  • Page 1 OWNER’S MANUAL BRUSHCUTTERS BC4310FW Caution • Before using our brushcutter, please read this manual carefully to understand the proper use of your unit. • Keep this manual handy. 848JJ393A2 (708)

  • Page 2: Table Of Contents

    18. When replacing cutting attachment or other components, be sure to use the parts supplied or recommended by ZENOAH. 19. When the unit is turned off, make sure the cutting attachment has stopped before the unit is set down.

  • Page 3: Set Up

    Set up ■ ENGINE • Using attached 4 bolts, secure the connection firmly with equal force. (F1) (1) Bolt ■ INSTALLING HANDLE 1. Loosen the 4 bolts on the handle bracket. (F2) 2. Insert the right handle (throttle lever is attached) and the left handle assembly into the bracket and retighten the bolts securely.

  • Page 4: Fuel

    Fuel WARNING • Keep open flames away from the area where fuel is handled or stored. • Mix and store fuel only in an approved gasoline container. Mix a regular grade gasoline (leaded or unleaded, alcohol-free) and a quality-proven motor oil for air cooled 2-cycle gasoline engine use. Recommended mixing ratio: Condition Gasoline : Oil...

  • Page 5: Cutting Work

    For normal operation, keep the wing nut loose (F12-2). • Choose a suitable recommended cutting attachment according to the object to be cut. (F13) Never use other cutting attachment not approved by ZENOAH. ■ WHEN USING A METAL BLADE 1.

  • Page 6: Maintenance

    (F19) • REPLACEMENT PLUG IS A Champion RCJ-6Y. ■ GEAR CASE • Supply ZENOAH genuine grease at every 25 hours of use. • Remove the cutter holders to arrange for old grease to exit. (F20) (1) Cutter holder (2) Plug ■...

  • Page 7: Storage

    L ... 1820mm W ... 630mm H ... 480mm Dry weight ... 7.2kg mixing rate 50 : 1 when using ZENOAH genuine oil mixing rate 25 : 1 when using market oil • Specifications are subject to change without notice...
  • Page 8 Head Office: 1-9, Minamidai, Kawagoe-city, Saitama, 350-1165 Japan Telephone: (+81)49-243-1117 Telecopier: (+81)49-243-7197 PRINTED IN JAPAN...
