Summary of Contents for Zenoah ZENOAH EBZ3000RH
- Page 1 EBZ3000RH 115 33 79-10 (005) Original Instruction OWNER’S MANUAL BLOWER EBZ3000RH GB-1...
-
Page 2: Explanation Of Symbols And Safety Warnings
1 m/s APPROVAL NUMBER OF CE EXHAUST EMISSION REGULATION (2002/88/EC) GB-2 : BLOWER (Back-pack garden blower) : Husqvarna Zenoah Co., Ltd. : EBZ3000RH (The year is clearly stated on the rating plate, followed by the serial number) 2006/42/EC of 17 May, 2006... -
Page 3: Table Of Contents
SAFETY FIRST Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail. -
Page 4: Specifications
EBZ3000RH 2. Specification Model Dimensions (LxWxH)** Dry weight* Fuel tank capacity Engine Type Displacement Air Filter Carburetor Ignition system Spark plug Muffler Operating Engine Speed Fuel Consumption Air Volume* Max. Air Volume** Max. Air Velocity* * with standard pipe ** without pipe Specifications are subject to change without notice. -
Page 5: For Safe Operation
It is extremely im- portant that you read and un- derstand the contents of this Operator’s manual. 10. Husqvar na Zenoah has a policy of continuous product development and therefore re- serves the right to modify the design and appearance of products without prior notice. - Page 6 EBZ3000RH 5. For safe operation doctor before getting worse. 8. The ignition system of your unit produces an electromagnetic field of a very low intensity. This field may interfere with some pacemakers. To reduce the risk of serious or fatal injury, persons with pacemaker should consult their physician and the pace- maker manufacturer before oper-...
-
Page 7: Using The Product
While using the product, if abnor- mal noise or vibration occurs, stop the engine immediately and con- tact the nearest ZENOAH servic- ing dealer for assistance. Check- ing the fan is very important. If the rotating fan should break up, it might lead to serious accidents. - Page 8 5. When replacing the any other part, or any lubricant, always be sure to use only ZENOAH prod- ucts or products which have been certified by ZENOAH for use with the ZENOAH product.
-
Page 9: Set Up
6. Set up FLEXIBLE HOSE and SWIVEL JOINT 1. Connect the blower and swivel joint with flexible hose. Clamp both ends of the flexible hose securely with the hardware supplied with the unit. NOTE A light lubricant may be used to ease assembly of flexible pipe to blower elbow. -
Page 10: Fuel
3 m (10 ft) away from the fueling point before starting the engine. • The Zenoah engines are lubricated by oil specially for- mulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle en- gine use (JASO FC GRADE OIL or ISO EGC GRADE). -
Page 11: Operation
8. Operation STARTING ENGINE IMPORTANT • Avoid operating the blower with the flexible tube and swivel joint disconnected. That will reduce the cooling air and the engine could be damaged by overheating. 1. Push the primer bulb until fuel flows out in the clear tube. -
Page 12: Maintenance
EBZ3000RH 9. Maintenance Maintenance, replacement, or repair of the emission control device and systems may be per- formed by any non-road engine repair establishment or individual. System / Compronent Air Filter Fuel Leaks Fuel Filter Fuel Line Spark Plug Muffler Muffler Spark Arrester Cooling Systrem Screws / Nuts / Bolts... - Page 13 9. Maintenance SPARK PLUG • The spark plug may gather carbon deposits on its firing end with reasonable use. Remove and inspect the spark plug every 25 hours and clean the elec- trodes as necessary with a wire brush. The spark gap should be adjusted to .025 in (0.65mm).
-
Page 14: Storage
EBZ3000RH 9. Maintenance AIR INLET NET IMPORTANT • Blowing air is taken in from the air inlet net. When air flow has dropped down during operation, stop the engine and inspect the air inlet net for blocking by obstacles. • Note that failure to remove any such obstacles may result in the engine becoming overheated and dam- aged. -
Page 15: Limited Warranty
(exhaust port) → carbon is built-up air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
