Page 1: Washing Machine
WASHING MACHINE ZWF 1111 W ZWF 1311 W Quick Installation Guide: visit our WEB SITE to view an install video www.video.uk.electrolux.com INSTRUCTION BOOKLET 132 981 530... -
Page 2: Important Safety Information
Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
Contents For the User Important Safety Information Your New Washing Machine Description of the Appliance Detergent dispenser drawer Child safety feature The Control Panel Operating Sequence Load the laundry Measure out the detergent Measure out the fabric softener Switch the machine on and select the desired programme/fabric Select the spin speed or the Rinse Hold option Select the desired options... -
Page 4: Your New Washing Machine
Your New Washing Machine Your new washing machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. Even small loads are washed “economically” because the amount of water used is regulated automatically according to the load and type of fabric. Automatic cooling of the wash water to 60°C ●... -
Page 5: Description Of The Appliance
Description of the Appliance This new machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. • The possibility of selecting the programme/temperature and all the options offered by this washing machine gives you truly “customised”... -
Page 6: The Control Panel
Maximum speeds for the different models are: for cottons: 1100 rpm for ZWF 1111 W and 1300 • rpm for ZWF 1311 W for synthetics fabrics and Wool: 900 •... - Page 7 • Select programme “Spin”. Select the spin speed by means of the relevant button and then depress the Start/Pause button. The water is emptied out and the laundry is spun at the selected spin speed. Attention! Before selecting the “Drain” or the “Spin” programmes, the selector dial must to be turned to the “O”...
- Page 8 Important! The first time you use the washing machine, when you switch it on, it may display a flashing zero and give an audible warning signal. This is due to the fact that the washing machine has performed a washing cycle during the manufacturer’s inspection tests, and this cycle has not been erased after its completion.
- Page 9 9 “Start/Pause” button This button has two functions: • Start: after you have selected the desired programme and options, press this button to start the washing machine. The light above the button will stop flashing and remain lit. • Pause: when you press this button again, the programme in progress is interrupted.
-
Page 10: Operating Sequence
If you select the will stop at the end of the programme with the water still in the tub. ZWF 1111 W 6. Select the desired options Depress the relevant buttons to select the required options. The corresponding light illuminates. -
Page 11: Start The Programme
If you select the “Night Cycle” will stop at the end of the programme with the water still in the tub. 7. Start the programme Press the “Start/Pause” button. The relevant light will stop flashing and the “Washing” and “Door” pilot lights illuminate and will remain lit. -
Page 12: Washing Hints
Washing Hints Do NOT overload the machine. Weigh the laundry the first few times you use the appliance. The average weights of the most common items are listed below as a guide: 1000g = 1 kg Sheet Pillow case Tablecloth Serviette Tea towel Linen hand towel... -
Page 13: Which Detergent
Which detergent?... To ensure you obtain the best wash results from your appliance, it is important to use the right detergent in your everyday wash, and only detergents recommended for use in automatic machines. To maintain the appearance of your clothes and household textiles and to make them last longer you should use different types of detergent for different washes, whether for whites, colours or delicates. -
Page 14: Wash Care Symbols
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. -
Page 15: Washing Programmes
This data is given purely as an indication: the consumption values may vary in relation to the quantity and type of laundry, the temperature of the water supply and the ambient temperature. The data refers to the highest temperature provided for each programme. The spin reduction is available only in the model ZWF 1111 W. Load Available options... - Page 16 * You can reduce the spin speed by means of the relevant button to adapt it to the fabrics to be spun. ** The spin reduction is available only in the model ZWF 1111 W. Available options...
-
Page 17: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. -
Page 18: Cleaning The Water Inlet Filter
• Place a container close to the pump to collect any spillage. • Pull out the emergency emptying hose, place it in the container and remove its cap. • When no more water comes out, unscrew the pump cover and remove it. Always keep a rag nearby to dry up spillage of water when removing the cover. -
Page 19: Emergency Emptying Out
Important! Every time you drain the water through the emergency emptying hose you must pour 2 litres of water into the main wash compartment of the detergent drawer and then run the Drain programme. This will activate the ECO valve and avoid the detergent being wasted. Emergency emptying out If the water is not discharged, proceed as follows to empty out the machine:... -
Page 20: Something Not Working
Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. IMPORTANT: if you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 21: Service And Spare Parts
Service Force, please visit the website at www.serviceforce.co.uk. For Customer Service in Ireland please contact us at the address below: Zanussi Electrolux - Electrolux Group (Irl) Ltd Long Mile Road - Dublin 12 Republic of Ireland Tel: +353 (0)1 4090751 Email: service.eid@electrolux.ie... -
Page 22: Guarantee Conditions
Guarantee Conditions Standard guarantee conditions We, Zanussi Electrolux, undertake that if, within 12 months of the date of the purchase, this ZANUSSI ELECTROLUX appliance or any part thereof is proved to be defective by reason only of faulty workmanship or... -
Page 23: Installation Instructions
MaximumZ 16 S Energy Water 85.cm 60.cm 63 cm 230-240 V/50 Hz 2050 W (10A) 0.05 MPa (0.5 bar) 0.80 (8.0 bar) 2.5 kg 2.5 kg 1100 rpm ZWF 1111 W 1300 rpm ZWF 1311 W 0.95 kWh 49 litres... -
Page 24: Unpacking
Unpacking The transport safeguard must be removed before putting the appliance into operation. Important ! You are advised to keep all the packaging for re-use in case the machine is to be transported again. After removing all the packaging, with assistance ●... -
Page 25: Water Inlet
Water inlet An inlet hose is supplied and can been found inside the machine drum. Do not use the hose from your previous machine to connect to the water supply. 1. Open the porthole and extract the inlet hose . 2. -
Page 26: Levelling
If your drain hose looks like this (see below) you do not require the “U” piece”. Just push the hose firmly into the standpipe. 2. Onto a sink outlet spigot. If the outlet spigot has not been used before, remove any blanking plug that may be in place. -
Page 27: Electrical Connection
Electrical connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance’s rating plate. - Page 28 From the Electrolux Group. The world’s No. 1 choice The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
