- Page 1 REFRIGERATOR ZUD 9124 A INSTRUCTION BOOKLET 2222683-36...
-
Page 2: Important Safety Instructions
Important Safety Instructions These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings of these warnings contact the Customer Care Department. Prior to Installation •... -
Page 3: Table Of Contents
• Under no circumstances should you attempt to repair the appliance yourself.Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Zanussi Service Force Centre. Contents Instructions for the User Important Safety Instructions ....2 Operation . -
Page 4: Operation
Operation Before use Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Setting the temperature The temperature inside the refrigerator is regulated by a thermostat control knob with 6 temperature positions and one «OFF»... -
Page 5: The -Star Compartment
-star compartment This compartment is suitable for freezing fresh food, for the storage of commercially frozen food and for ice cube making. Freezing fresh food To freeze fresh foods it is not necessary to change the setting of the thermostat knob. However, for a quicker freezing operation, turn the thermostat knob to the coldest setting;... -
Page 6: Health And Safety Guidelines
Health and Safety Guidelines Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever. The following tips should help you to ensure that the food in your home is in as perfect condition as possible. -
Page 7: Defrosting
Defrosting The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via the pipe, into a tray located below the appliance, where it evaporates. Important To avoid defrost water overflowing and dripping onto the food in the fridge, periodically clean the water discharge hole (F) situated under the salad drawers. -
Page 8: Maintenance And Cleaning
Maintenance and Cleaning Warning Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Important This appliance contains hydrocarbons in cooling unit maintenance recharging must therefore only be carried out by authorised technicians. Internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). -
Page 9: Something Not Working
Something not Working? Before contacting your local Service Force Centre check the following points. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. Symptom No power to appliance The light does not come on... -
Page 10: Service And Spare Parts
Customer Care Department For general enquiries concerning your Zanussi appliance or for further information on Zanussi products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.zanussi.co.uk... -
Page 11: Guarantee Conditions
Standard guarantee conditions We, Zanussi, undertake that if within 24 months of the date of purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: •... -
Page 12: Technical Specifications
Technical Specifications DIMENSIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY(*) TOTAL GROSS CAPACITY NET CAPACITY Fridge NET CAPACITY STAR RATING (*) This figure is based on standard test results in accordance with European Standard EN153. Actual consumption will depend on how the appliance is used and where it is located. -
Page 13: Door Reversal
Door reversal To reverse the opening direction of the door, proceed as shown in the figures: Attention After completion of the door reversing operation, check that the door gasket adheres to the cabinet. If the ambient temperature is cold (i.e. in Winter), the gasket may not fit perfectly to the cabinet. -
Page 14: Inner Door Reversal
Inner door reversal 180°... -
Page 15: Electrical Connection
Electrical Connection WARNING THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. If the plug that is fitted to your appliance is not suitable for your socket outlet, it must be cut off and the appropriate plug fitted. -
Page 16: Building-In Instructions
Building-in instructions Before carrying out any work, remove the plug from the power socket. Grid preparation Left door opening: Remove the left side (A) of the grid cutting it from the rear (see figure). DO002/2 Right door opening: Remove the right side (B) of the grid cutting it from the rear (see figure). - Page 17 2. Push the appliance into place. The plug socket necessary for connection of the appliance to the electricity supply should be positioned, so that the plug is not placed in the recess. 3. To adjust the height proceed as follows: - Loosen or tighten the two front feet.
- Page 18 click click Upper part of kitchen furniture panel Möbeltür Innenseite 45°...
-
Page 19: Fitting The Plinth
7. Refit the covering strip (A). Fitting the plinth • For an opening height dimension A=820 mm and a plinth height dimension a=100 mm, the plinth may be fitted without adjustments. The same applies to an opening height dimension B=870 mm and a plinth height dimension b=150 mm. - Page 20 © Electrolux plc 2006...
