- Page 1 Z Z A A N N U U S S S S I I REFRIGERATOR ZRC 077W INSTRUCTION BOOK 200381077 A/ZE/58-1. (07.)
-
Page 2: Guide To Use The Instruction Book
This instruction book contains safety precautions, information on use and helpful hints and tips. To ensure you use this appliance effectively and safely, please read this instruction book carefully before installing or using this appliance and retain for future reference. The symbols below help you to find things more easily: Safety precautions Warnings and Safety information... -
Page 3: Important Safety Instructions
IMPOR ANT S IMPOR ANT S These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings or these warnings contact the Customer Care Department. Prior to installation Check the appliance for transport damage. - Page 4 Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance. The Appliance and the Environment This appliance does not contain gasses which could damage the ozone layer. Avoid damaging the cooling unit. The packaging used on this appliance marked with the symbol is recyclable.
-
Page 5: Table Of Contents
Instructions for the User Guide to use the instruction book Important Safety Instructions Instructions for the User Description of the Appliance Using the Appliance Before Use To Start the Appliance Thermostat Control Hints for storage Storage Shelf The Ice-making Compartment Hints and Tips Food Storage Frozen food storage... -
Page 6: Instructions For The User
General information This appliance is designed for the refrigeration of food in a domestic home. It also has an ice-making compartment. Description of the appliance 1. Ice-making compartment 2. Rating plate 3. Ice tray 4. Wire shelf 5. Drip tray 6. -
Page 7: Using The Appliance
Using the Appliance Before Use Remove all securing tapes. Wash the inside of the appliance with lukewarm water with a little bicarbonate of soda added (5 ml to 0,5 litre of water). Do not use soap or detergent as the smell may linger. -
Page 8: Storage Shelf
Storage Shelf The shelf inside the appliance has a flap on the left side that makes storing large sized bottles possible. The door shelves taken out of appliance can be used for serving foods (fruit, salads, etc.) The Ice-making Compartment This compartment is suitable for the storing of commercially frozen food and for making and storing ice cubes. -
Page 9: Storage Time Chart
Time and method of storage of fresh foods in the refrigerator Foods Raw meat Cooked meat Roasted meat Raw minced meat Cooked minced meat Cold cuts Fresh fish Cooked fish Tinned fish, open Fresh chicken Fried chicken Fresh duck, goose Roasted duck, goose Butter unopened Butter opened... -
Page 10: Maintenance And Cleaning
Maint Maint Before any maintenance of cleaning work is carried out DISCONNECT the appliance from the ELECTRICITY SUPPLY. Internal Cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5 ml to 0.5 litre of water). Rinse and dry thoroughly. -
Page 11: Something Not Working
Something N Something N If the appliance is not working correctly, please carry out the following checks before contacting your local Service Force Centre. Problem No power to the No power at the socket. appliance There is a power cut. The fuse has blown. -
Page 12: Service And Spare Parts
For general enquiries concerning your Zanussi - Electrolux appliance or for further information on Zanussi - Electrolux products, please contact our Customer Care Department by letter or telephone at the adresses below or visit our website at www.zanussi-electrolux.co.uk Customer Services Department... -
Page 13: Guarantee Conditions
Guar Guar We Zanussi - Electrolux undertake that if within 12 months of the date of the purchase this ZANUSSI - ELECTROLUX appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, the company will, at... -
Page 14: Instructions For The Installer
Hold the spacer as shown on the Fig., using fine strokes of hammer put it in its place. or the Ins uctions f or the Ins ZRC 077W Ice-making comp.: 5 Fresh food comp.: 65 Ice-making comp.: 5 Fresh food comp.: 62 0,299... -
Page 15: Ventilation Requirements
Ventilation Requirements The appliance must have adequate ventilation to ensure correct operation. Diagram shows the ventilation requirements when installed: A* Under a worktop, or cupboard. * The clearance space of 10 cm above the appliance may be reduced to 5 cm providing a clearance space 2.5 cm is left on either side of the appliance. -
Page 16: Electrical Connection
Electrical connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. This appliance must be earthed. The manufacturer declines any liability should these safety measures not be observed. Electrical Requirements Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance rating plate. - Page 20 © Electrolux plc 2007 ELECTROLUX HOME PRODUCTS OPERATIONS EUROPE From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
