REFRIGERADOR
REFRIGERATOR
FRIGORIFICO
ZO 29 Y
ZO 29 S
ZO 29 N
LIBRO DE INSTRUCCIONES
INSTRUCTION BOOKLET
MANUAL DE INSTRUÇÕES
2222 151-92

Advertisement

Table of Contents
loading

Related Manuals for Zanussi ZO 29 N

Summary of Contents for Zanussi ZO 29 N

  • Page 1 REFRIGERADOR REFRIGERATOR FRIGORIFICO ZO 29 Y ZO 29 S ZO 29 N LIBRO DE INSTRUCCIONES INSTRUCTION BOOKLET MANUAL DE INSTRUÇÕES 2222 151-92...
  • Page 2 Please fill in the necessary details on the Card Certificate and send it to the Zanussi Centre covering the area in which the appliance is to be installed. (See list of Zanussi network centres).

  • Page 3: General Safety

    It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings.

  • Page 4: Table Of Contents

    Installation Location Rear spacers Cleaning the interior Changing the opening direction of the door Changing the opening direction of the compartment door Technical specification Electrical connection Operation - Temperature adjustment Fresh food refrigeration Movable shelves Positioning the door shelves Frozen food storage Thawing Making ice cubes Defrosting...

  • Page 5: Installation

    If this refrigerator featuring magnetic door seals is to replace an older appliance having a spring lock on the door or lid, be sure to make that spring lock unusable before you discard the old appliance. This will prevent it from becoming a death-trap for a child.

  • Page 6: Cleaning The Interior

    Important It is essential that the appliance be connected to an efficient earth tap. For this purpose the supply cable plug incorporates a special earth contact. If the sockets of your domestic wiring system are not earthed, have the appliance connected to a separate earth wire by a qualified electrician in accordance with existing safety regulations.

  • Page 7: Changing The Opening Direction Of The Door

    Changing the opening direction of the door Unplug the appliance before performing the following operations: Remove the ventilation grille (D-Fig. 3). Unscrew the bottom hinge (E-Fig. 3). Remove the door from the upper pivot (A-Fig. 4). Remove the pivot and the washer (A+B-Fig. 4) from the upper hinge (C), then mount these on the opposite side.

  • Page 8: Changing The Opening Direction Of The Compartment Door

    Changing the opening direction of compartment door (Fig. 6) Fig. 6 Remove pin (1). Remove the door. Pin (4) could drop out when this operation is carried out; if so, it must be retrieved for fitting on the opposite side. Remove bush (5) and fit it on the opposite side.

  • Page 9: Use

    Operation - Temperature adjustment Turn the thermostat knob clockwise beyond position « O » to the required setting. A medium setting is generally the most suitable. Temperature is adjusted automatically and may be increased (less cold) by turning the knob towards the lower numbers, or may be decreased (colder) by turning it towards the higher numbers.

  • Page 10: Movable Shelves

    Movable shelves The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired. For better use of space, the front half-shelves can lie over the rear ones. Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be adjusted in height.

  • Page 11: Frozen Food Storage

    Frozen food storage The compartment marked by the symbol suitable for storing frozen food and, to obtain the best results, make sure the thermostat knob is set near the coldest setting (if ambient temperature is low-i.e., less than 20 C - it is necessary to adjust the conveyor in such a way as to reduce the temperature in the refrigerator compartment).

  • Page 12: Maintenance

    Before carrying out any maintenance operation, always disconnect the plug from the wall socket. Periodical cleaning Wash the interior of the appliance with lukewarm water and sodium bicarbonate. Clean cabinet outer surfaces with a silicone-wax spray. The condenser and compressor should be cleaned using a brush or a vacuum cleaner.

This manual is also suitable for:

Zo 29 sZo 29 y
