- Page 1 Z Z A A N N U U S S S S I I FRIDGE - FREEZER ZNB 4051 INSTRUCTION BOOK 200370769 A/ZE/45. (06.)
- Page 2 This instruction book contains safety precautions, information on use and helpful hints and tips. To ensure you use this appliance effectively and safely, please read this instruction book carefully before installing or using this appliance and retain for future reference. The symbols below help you to find things more easily: Safety precautions Warnings and Safety information...
-
Page 3: Important Safety Instructions
IMPOR ANT S IMPOR ANT S These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings or these warnings contact the Customer Care Department. Prior to installation Check the appliance for transport damage. -
Page 4: Table Of Contents
Instructions for the User Important Safety Instructions General Information Description of the Appliance Switch and indicator set Display background colour Using the Appliance Putting it into use Controlling the temperature, seeting How to use the refrigerator Drawer Shopping mode The Refrigerator Storage Shelves Storage Times The Freezer... -
Page 5: Instructions For The User
UCTIONS F UCTIONS F General information The official designation of the appliance is "frostfree refrigerator-freezer combination compressor and freezer placed in the lower part". The appliance has - besides the general services - a freezer with its own door and is completely separated from the other unit. -
Page 6: Switch And Indicator Set
Switch and indicator set The following components can be found under a cover in the top frame: A. Button ON/OFF Switches the appliance on and off. B. Fridge temperature display By default it shows he medium temperature inside the refrigerator. Should the temperature be higher than 9 °C, a "-"... -
Page 7: Display Background Colour
M. Alarm light (red) In the event of an abnormal temperature rise inside the freezer (e.g. power cut) this warning light will start to flash and a buzzer will sound. After the temperature has returned to normal, the warning light will continue to flash, although the buzzer has stopped. -
Page 8: Drawer
Drawer The drawer is suitable for storing fruit and vegetables. There is a separator inside the drawer that can be placed in different position to allow for the subdivision best suited to personal needs. ACTION COOL mode The ACTION COOL function is suited for quick cooling of large quantities of goods in the refrigerator. -
Page 9: Storage Shelves
Storage Shelves The shelves in the refrigerator compartment are adjustable to allow for the storage of large items. To re-arrange the shelves, open the door to 90°. Storage Times The storage chart at the end of the instruction book gives information on storage times in the refrigerator compartment. -
Page 10: Frozen Food Storage
Frozen Food Storage When first starting the freezer or if the freezer has been out of use for some time, we advise you to run your appliance for at least 2 hours before storing frozen food. Do not exceed the storage period indicated by the manufacturer. -
Page 11: Hints And Tips
Normal Operating Sounds You may hear faint gurgling or bubbling sounds when the refrigerant is pumped through the coils or tubing. When the compressor is on, the refrigerant is being pumped round and you will hear a whirring sound or pulsating noise from the compressor. -
Page 12: Maintenance And Cleaning
Maint Maint Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Internal Cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5 ml to 0.5 litre of water). Rinse and dry thoroughly. -
Page 13: Defrosting
Defrosting Defrosting is automatic in this model. To Change the Light Bulb Should the light fail to work you can change it as below: Break the circuit of the appliance. Press the rear hook (1) of the lampcover by a screwdriver and at the same time pull and rotate the cover in the direction indicated by the arrow (2). -
Page 14: Something Not Working
Something N Something N If the appliance is not working correctly, please carry out the following checks before contacting your local Service Force Centre. Problem No power to the appliance No power at the socket. There is a power cut. The fuse has blown. -
Page 15: Service And Spare Parts
For general enquiries concerning your Zanussi - Electrolux appliance or for further information on Zanussi - Electrolux products, please contact our Customer Care Department by letter or telephone at the adresses below or visit our website at www.zanussi-electrolux.co.uk Major Appliances - Customer Care Department... -
Page 16: Guarantee Conditions
Guar Guar We Zanussi - Electrolux undertake that if within 12 months of the date of the purchase this ZANUSSI - ELECTROLUX appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, the company will, at... -
Page 17: Instructions For The Installer
0.5 litres of water). Rinse and dry thoroughly. Do not use detergents, abrasive powders, highly perfumed cleaning products, wax polishes or cleaning products containing bleach or alcohol. or the Ins uctions f or the Ins ZNB 4051 Refrigerator: Freezer: 122 Refrigerator: Freezer: 109 2010 1,12... -
Page 18: Levelling The Appliance
In the bag of the accessories there are two spacers which must be fitted in the two top corners. Slacken the screws and insert the spacer under the screw head, the re-tighten the screws. Levelling the Appliance When placing the appliance ensure that it stands level. This can be achieved by two adjustable feet at the bottom in front. - Page 19 removing it from the cabinet, slightly tilting both doors. Do not forget to remove the plastic spacer (b) under the hinge. (fig. 2) 5. Take off the refrigerator door by pulling it slightly downwards. 6. Take off the freezer door by pulling it slightly upwards.
-
Page 20: Electrical Connections
Electrical Connection Electrical Connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. This appliance must be earthed. The manufacturer declines any liability should these safety measures not be observed. Electrical Requirements Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance... -
Page 21: Storage Chart
Time and method of storage of fresh foods in the refrigerator Foods Raw meat Cooked meat Roasted meat Raw minced meat Cooked minced meat Cold cuts Fresh fish Cooked fish Tinned fish, open Fresh chicken Fried chicken Fresh duck, goose Roasted duck, goose Butter unopened Butter opened... - Page 24 © Electrolux plc 2006 ELECTROLUX HOME PRODUCTS OPERATIONS EUROPE From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
