- Page 1 REFRIGERATOR- FREEZER ZI 310 DIS INSTRUCTION BOOKLET 2222 209-42...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information. -
Page 3: Table Of Contents
CONTENTS Instructions for the user Important Safety Information Description of the appliance Operation Before use Setting the temperature The freezer compartment Freezing fresh food Frozen food storage Thawing Making ice cubes Fresh food refrigeration Normal operating sounds Hints and Tips Maintenance and Cleaning Internal cleaning External cleaning... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE A- Storage wire baskets B - Bottle storage wire basket C- Freezing fresh food... -
Page 5: Operation
OPERATION Control panel Before using Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Setting the temperature The temperature inside the refrigerator and the freezer is regulated by a single thermostat (B) with 6... -
Page 6: Frozen Food Storage
Storage of frozen food When first starting-up or after a period of use, before putting the products in the freezer compartment let the appliance run for at least two hours on the coldest setting, then turn the thermostat knob to the normal opertion position. -
Page 7: Hints And Tips
HINTS AND TIPS Food Storage ¥ To obtain the best results from your appliance, neither hot foods nor liquids which may evaporate, should be placed in the larder compartment. ¥ Keep the time between buying chilled food and placing it in your fridge as short as possible. ¥... -
Page 8: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly. NEVER USE DETERGENTS, ABRASIVE POWDERS, HIGHLY PERFUMED CLEANING PRODUCTS OR WAX... - Page 9 Reconnect the appliance to the mains or reset the thermostat to a functioning position. After letting the appliance run for a least half an hour, replace the previously removed food into the compartment. Important When defrosting the freezer, the fridge is also controlled by the thermostat and will not be operational during this period.
-
Page 10: Something Not Working
SOMETHING NOT WORKING Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. Before contacting your local Service Force Centre, check the following points: Symptom No power to the appliance The light does not come on... -
Page 11: Service And Spare Parts
The model and serial number of the appliance (found on the rating plate) The purchase date CUSTOMER CARE DEPARTMENT For general enquiries concerning your Zanussi appliance or for further information on Zanussi products, please contact our Customer Care Department by letter or telephone as follows:- Customer Care Department... -
Page 12: Guarantee Conditions
Standard guarantee conditions We, Zanussi, undertake that if within 24 months of the date of the purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 13: Technical Specification
TECHNICAL SPECIFICATIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY * GROSS CAPACITY NET CAPACITY STAR RATING This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located. 220-240 V / 50 Hz 110 W 1.00 kWh... -
Page 14: Installation
INSTALLATION Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. -
Page 15: Electrical Connection
The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Zanussi Service Force Centre whose address is listed in the Customer Care Booklet which accompanies your instruction manual. -
Page 16: Door Reversal
Instructions for totally built-in appliances Door reversibility D337 Right-hand opening Remove pins (P) and (P1) . Left-hand opening Remove (P) from both sides and also remove the door . Remove centre hinge (A) from the left side and (B)- (C)-(D) from the right side. Refit (B)-(C)-(D) on the left side and (A) on the right side. - Page 17 Push appliance into housing until stop strip (A) touches the kitchen unit. Open the door and push the appliance against the side of the kitchen unit opposite to that of appliance hinges. Fasten the appliance with 4 screws provided in the kit included with the appliance.
- Page 18 Separate parts A, B, C, D as shown in the figure Place guide (A) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes. After having drilled holes, fix the guide with the screws supplied.
- Page 19 Should the lining up of the furniture door be necessary, use the clearance of slots. At the end of operations, it is necessary to check if the door of the furniture closes properly. Fix cover (D) on guide (B) until it clips into place. If the appliance is fixed to the side of the kitchen unit, simply slacken the screws in fixing brackets (E), move the brackets as shown in the figure and re-...
