Summary of Contents for ETC CarPlay NV17
- Page 1 CarPlay CarPlay NV17 NV17 Manual Manual - MODEL : NV17-AV_MODULE_C_V001 - DATE : 2019.01.14...
- Page 2 Index Index 1. Main Spec 2. Dimension 3. External Appearance 4. Connector Pin Assignment 5. Product Composition 6. Setting 7. Install Manual 8. Q & A...
- Page 3 1. Main Spec. 1. Main Spec. 1. Input Spec. - 1 x USB Input - 1 x Microphone Input - 1 x Real Analog Touch Input 2. Output Spec. - 1 x LVDS(HDMI Connector) Output - 1 x Audio L/R (3.5Ф Stereo Jack) Output - 1 x Mono Speaker 3.
- Page 4 2. Dimension 2. Dimension 82mm * 134.5mm * 23mm 82mm 23mm 134.5mm * This can change under manufacturer’s circumstance...
-
Page 5: External Appearance
3. External Appearance 3. External Appearance DIP S/W IMAGE PROGRAM LCD-OUT POWER/CAN Digital Video Analog Rear R-TOUCH Camera... - Page 6 3. External Appearance 3. External Appearance Smartphone Connection Microphone In Made Switch to Enter Setting Speaker Touch POWER/CAN LVDS&UART...
-
Page 7: Connector Pin Assignment
4. Connector Pin Assignment 4. Connector Pin Assignment *Touch Connect *POWER Connect ① ② ③ ④ ① ② ① ACC ① Y- ② X- ② GND ③ Y+ ④ X+... -
Page 8: Product Composition
5. Product Composition 5. Product Composition Interface 1 EA TOUCH Cable 2 EA HDMI Cable 1 EA AUX Cable 1 EA SPEAKER 1 EA SPEAKER Cable 1 EA Microphone 1 EA Power Cable 1 EA... - Page 9 6. Setting 6. Setting ① ② Press the setting button for 3 When the above menu appears, press the setting seconds. button for 3 seconds. ③ ④ Correct the touch when the screen Vehicle must be powered on without OEM touch changes.
- Page 10 7. Install Manual 7. Install Manual Iphone Interface Screen...
- Page 11 8. Q & A 8. Q & A 1. Check the LED status first when interface failure.. - If there is no abnormality after the power is applied, the green LED flashes in units of 1 second. - If the red LED flashes for 1 second, there is no. - If the red LED is on continuously, the interface itself is bad.
