- Page 1 GAS HOB MODEL ZGF 642 INSTRUCTION BOOKLET Please read this instruction booklet before using the appliance...
-
Page 2: Important Safety Information
Important Safety Information You MUST read hese warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 01635 521313 Installation This hob must be installed by qualified personnel, according to the manufacturer’s instructions and to the relevant British Standards. -
Page 3: Table Of Contents
For the User Description of the Hob Operation Maintenance and Cleaning Something Not Working Service and Spare Parts Peace of Mind for 24 Months Guide to Use the instructions The following symbols will be found in the text to guide you throughout the Instructions: Safety Instructions Step by step instructions for an operation... -
Page 4: Description Of The Hob
Description of the Hob Hob Top Auxiliary Burner Semi-rapid Burners Rapid Burner Control knob for front left burner (auxiliary) Control knob for back left buner (semi-rapid) Control knob for back right burner (semi-rapid) Control knob for front right burner (rapid) INSTALLATION Any gas installation must be carried out by a registered CORGI installer, and in... -
Page 5: Operation
Operation HOB BURNERS To light a burner, turn the relevant knob anticlockwise to maximum position and push down the knob to ignite. If the burner does not ignite, turn the control knob to zero, and try again. When switching on the mains, after installation or a power cut, it is quite normal for the spark generator to be activated automatically. -
Page 6: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. -
Page 7: Something Not Working
Something Not Working? If the hob is not working correctly, please carry out the following checks before contacting your local Zanussi Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 8: Service And Spare Parts
Customer Care Booklet. Peace of Mind for 24 Months ZANUSSI GUARANTEE CONDITIONS We, Zanussi, undertake that if, within 24 months of the date of the purchase, this Zanussi appliance or any part thereof is proved to be defective by any... -
Page 9: Technical Data
Instructions for the Installer Engineer technical data OVERALL DIMENSIONS Width: 580 mm. Depth: 510 mm. Height: 72 mm. Weight: 12 Kg. CUT OUT DIMENSIONS Width: 560 mm. Depth: 480 mm. Thickness: 30 mm. Ignition HT Spark Spark Generator Ispra Control's BF 50046-06 , 220-240V 0.6 VA T 120 Spark Gap Fixed Rear Left Burner (semi rapid) -
Page 10: Important Safety Requirements
Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). Detailed recommendations are contained in the following British Standards Codes Of Practice: B.S. 6172/ B.S. -
Page 11: Installation
Installation IMPORTANT This hob must be installed by qualified personnel to the relevant British Standards. Any gas installation must be carried out by a registered CORGI installer. The manufacturer will not accept liability, should the above instructions or any of the other safety instructions incorporated in this book be ignored. -
Page 12: Building In
Building In Building over a cupboard or drawer If the hob is to be installed above a cupboard or drawer it will be necessary to fit a heat resistant board below the base of the hob on the underside of the work surface. -
Page 13: Electrical Connection
Electrical connections Any electrical work required to install this hob should be carried out by a qualified electrician or competent person, in accordance with the current regulations. THIS HOB MUST BE EARTHED. The manufacturer declines any liability should these safety measures not be observed. -
Page 14: Wiring Diagram
Wiring Diagram 1. TAPS IGNITOR SWITCHES 2. IGNITOR UNIT... -
Page 15: Fault Finding
Fault Finding Preliminary Electrical Systems Check Blue Brown Green Yellow START Isolate appliance and carry out: A: Earth Continuity check. Blue Green Brown Yellow Has inlet fuse blown? Inlet wiring faulty. Rectify any fault. PLUG (with cover removed) Earth Wire Green/Yellow Neutral Wire Blue... - Page 16 Ignition System / Gas Ignition Ignitor does not spark Check plug top fuse and replace if necessary Check polarity and earth continuity of supply point Check earth continuity of appliance Check continuity from 'N' on the mains connector block and "O" on the ignitor unit Check continuity from 'L' on the mains connector block and the...
-
Page 17: Commissioning
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. - Turn the gas tap to the MAX position and ignite. - Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times. -
Page 18: Servicing
Servicing Repais may only be carried out by CORGI registered engineers. A: Removal Of Hob Top 1. Remove all control knobs, pan supports, burner caps and burner crowns. 2. Remove 2 screws for each burner. 3. Remove 4 fixing screws from the pan support hinges, and remove the hinges from the hob.
