Zanussi ZDF490 Instruction Booklet

Built-in electric double oven
Hide thumbs

Advertisement

BUILT-IN ELECTRIC

DOUBLE OVEN

ZDF490
INSTRUCTION BOOKLET

Advertisement

loading

  Related Manuals for Zanussi ZDF490

  Summary of Contents for Zanussi ZDF490

  • Page 1: Double Oven

    BUILT-IN ELECTRIC DOUBLE OVEN ZDF490 INSTRUCTION BOOKLET...
  • Page 2: Technical Details

    TECHNICAL DETAILS MODEL NO. ZDF 490 Voltage: Wattage: Height: Width: Depth: Weight This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC. 230/240 Volts AC 50Hz 4.5/4.9kW 897mm 592mm 563mm (excluding handles and knobs) 55kg...
  • Page 3: Table Of Contents

    CONTENTS Technical Details ... 2 Contents ... 3 Safety ... 5 Before Installation ... 5 During Operation ... 5 After Use ... 6 General ... 6 Installation Instructions ... 7 Things You Need to Know ... 7 Warnings ... 7 Things to Note ...
  • Page 4 CONTENTS The Top Oven ... 21 Uses of the Top Oven ... 21 Selecting the Top Oven... 21 Things to Note ... 22 To Fit the Top Oven Shelf ... 22 Hints and Tips ... 22 The Main Fan Oven ... 23 Uses of the Fan Oven ...
  • Page 5: Safety

    SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT YOU UNDERSTAND THEM ALL BEFORE INSTALLING OR USING THE APPLIANCE. PLEASE READ CAREFULLY BEFORE INSTALLATION This appliance is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the appliance, has been removed before the...
  • Page 6: After Use

    Ensure that you support the grill pan when it is in the withdrawn or partially withdrawn position. Ensure that all vents are left unobstructed to ensure ventilation of the oven cavity. You must ensure that the grill control is in the ‘OFF’ position when the timer control has been set for automatic cooking.
  • Page 7: Installation Instructions

    INSTALLATION INSTRUCTIONS THINGS YOU NEED TO KNOW WARNINGS · This appliance must be installed by a qualified electrician/competent person. Safety may be impaired if installation is not carried out in accordance with these instructions. · This appliance must be earthed. ·...
  • Page 8: Recommended Cabinet Dimensions

    RECOMMENDED CABINET DIMENSIONS (IN MILLIMETRES) Cross section through cabinet showing oven positioned Fig. 2 Built In Installation...
  • Page 9: How To Finish Unpacking

    HOW TO FINISH UNPACKING · Place appliance next to the cabinet in which it will be installed. · Remove the appliance packing except for bottom tray which should be left in position until the appliance is ready to be fitted into its cabinet.
  • Page 10: Connecting To The Mains Terminal

    · Lift cover and remove screw from cable clamp. See Fig. 5. Fig.5 CONNECTING TO MAINS TERMINAL Warning: This appliance must be earthed. · Make connection as shown in Fig. 6 by proceeding as follows:- Fig.6 · Preform wires to the appropriate shape to suit fitting into the mains terminal block.
  • Page 11: Fitting Into The Cabinet

    FITTING INTO THE CABINET IMPORTANT: Ensure that the oven is switched off at the wall before any further work is carried out. · Using a tape measure establish the internal width of the cabinet. Refer to page 7 if greater than 565mm.
  • Page 12: Introduction

    INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED GETTING TO KNOW YOUR APPLIANCE Top Oven Temperature Control Top Oven Neon Top Oven Function Selector Electronic Timer Main Oven Temperature Control Main Oven Neon...
  • Page 13: Rating Plate

    INTRODUCTION RATING PLATE This is situated on the lower front frame of the appliance and can be seen upon opening the top cavity door. Alternatively the rating plate may also be found on the back or top of some models (where applicable).
  • Page 14: Grill And Oven Furniture

    GRILL AND OVEN FURNITURE The following items of grill and oven furniture have been supplied with the appliance. If you require replacements of any of the items listed below please contact your local Service Force Centre, quoting the relevant part number. 1 grill pan (311409401) 1 grill pan handle...
  • Page 15: The Oven Timer

    THE OVEN TIMER COOK TIME END TIME COUNTDOWN TIME DECREASE CONTROL SELECTOR CONTROL G INCREASE CONTROL NOTE: The time of day must be set before the main oven will operate manually. 1. SET THE TIME OF DAY The oven has a 24 hour clock. When the electricity supply is first switched ON, the display will show 12.00 and the 'Time' ( indicator neon will flash as Fig.
  • Page 16: Setting The Oven Timer

    TO CANCEL THE COUNTDOWN If you change your mind and want to cancel the 'Countdown', press the Selector Control button until the 'Countdown' indicator ( decrease control ( - ) until 0.00 shows in the display as Fig. 5. The 'Countdown' indicator ( continue to flash for a few seconds and the return to the time of day.
  • Page 17 B) TO SET THE TIMER TO SWITCH OFF ONLY Ensure the electricity supply is switched ON and that the correct time of day is displayed, e.g. 10.00am as Fig. 9. ii) Place food in oven. iii) To set the length of cooking time, press the Selector Control button until the 'Cook Time' ) indicator is illuminated.
  • Page 18: Automatic Cooking

    6. THINGS TO NOTE In the event of an interruption of the electricity supply, the timer will reset itself to zero, and all programming will be cancelled. 7. AUTOMATIC COOKING It is advisable to leave food in the oven for as short a time as possible before automatic cooking.
  • Page 19: The Grill

    THE GRILL USES OF THE GRILL CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY SELECTING THE GRILL · Select the grill function. · Turn the top oven temperature control knob to the right as far as it will go.
  • Page 20: Hints And Tips

    HINTS AND TIPS · Most foods should be placed on the grid in the grill pan to allow maximum circulation of air to lift the food out of the fats and juices. Food such as fish, liver and kidneys may be placed directly on the grill pan base if preferred.
  • Page 21: The Top Oven

    THE TOP OVEN USES OF THE TOP OVEN The top oven is the smaller of the two ovens. It is designed for cooking smaller quantities of food. It gives especially good results if used to cook fruit cakes, sweets and savoury flans or quiche. The top oven is also ideal for use as warming compartment to warm dishes and keep food hot.
  • Page 22: Things To Note

    THINGS TO NOTE 1. The top oven indicator neon will glow until the oven has reached the desired temperature and then go out. It will turn ON and OFF periodically during cooking showing that the temperature is being maintained. 2. The cooling fan for the controls may operate, after a period of time.
  • Page 23: The Main Fan Oven

    THE MAIN FAN OVEN USES OF THE FAN OVEN PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without preheating however, you may find you need to add an extra 5-10 minutes on the recommended cooking times. For recipes needing high temperatures, e.g.
  • Page 24: Hints And Tips

    HINTS AND TIPS · Arrange the shelves in the required positions before switching the oven ON. Shelf positions are numbered from the bottom upwards. · When cooking more than one dish in the fan oven, place dishes centrally on different shelves rather than cluster several dishes on one shelf, this will allow the heat to circulate freely for the best cooking results.
  • Page 25: Oven Cooking Chart

    OVEN COOKING CHART The oven temperatures are intended as a guide only. temperatures by 10°C to suit individual preferences and requirements. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen Sponges Victoria Sandwich Madeira Rich Fruit Christmas Gingerbread Meringues Flapjack Shortbread Casseroles: Beef/Lamb...
  • Page 26: Roasting Chart

    ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES – Rare : 50-60°C; Medium : 60-70°C; Well done : 70-80°C MEAT Beef Beef, boned Mutton and Lamb Pork and Veal Chicken Turkey and Goose Duck Pheasant Rabbit Potatoes with meat Potatoes without meat The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be required to allow for personal requirements and the shape and texture of the meat.
  • Page 27: Defrosting

    DEFROSTING USES OF DEFROST FEATURE This main oven function defrosts most foods faster than more conventional methods. suitable for delicate frozen foods which are to be served cold, e.g. cream filled gateaux, cakes covered with icings or frostings, cheesecakes, biscuits, scones, etc.
  • Page 28: Care And Cleaning

    CARE AND CLEANING BEFORE CLEANING ALWAYS ALLOW THE COOLING FAN TO COOL THE APPLIANCE DOWN BEFORE SWITCHING OFF AT THE ELECTRICITY SUPPLY. CLEANING MATERIALS Before using any cleaning materials on your appliance, check that they are suitable and that their use is recommended by the manufacturer.
  • Page 29: Cleaning The Shelves, Wirework Runners And Grill/Oven Furniture

    CLEANING THE SHELVES, WIREWORK RUNNERS AND GRILL/OVEN FURNITURE All removable parts, except the grill pan handle, can be washed in the dishwasher. The meat tin, grill pan, grill pan grid, oven shelves and wirework runners may be cleaned using a soap impregnated steel wool pad.
  • Page 30: Cleaning Between The Outer And Inner Door Glass

    TO REPLACE THE OUTER GLASS 1. Open the oven door with care and place in the park position at an angle of approximately 30°. 2. Holding the oven glass with both hands, gently place the locators into the holes of the brackets at the bottom of the oven door.
  • Page 31: Something Not Working

    SOMETHING NOT WORKING? Before calling an Engineer please carry out the following checks, you may be able to solve the problem without the expense of an Engineer. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee.
  • Page 32: Service And Spare Parts

    Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquires concerning your Zanussi appliance, or for further information on Zanussi products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.zanussi.co.uk...
  • Page 33: Guarantee Conditions

    Standard guarantee conditions We, Zanussi, undertake that if within 24 months of the date of the purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·...
  • Page 34: Notes

    NOTES...
  • Page 35 NOTES...
  • Page 36 In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed. ZANUSSI 55 – 77 HIGH STREET, SLOUGH, BERKSHIRE,...
