This product should be serviced by an authorised ZANUSSI Service Centre, and only genuine spare parts should be used. Under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning.
Page 3
Environment Protection This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. Avoid damaging the cooling unit, especially at the rear near the heat exchanger.
Description of the appliance Installation Positioning Rear spacers Before using The electrical connections Technical specification Door reversibility Operation Refrigerator/Freezer - Starting-up and temperature regulation Health and safety guidelines Freezing fresh food Frozen food storage Thawing Ice making Fresh food refrigeration Movable shelves Positioning the door shelves Cool check temperature guide...
DESCRIPTION OF THE APPLIANCE A - Ice trays B - Shelf for freezing fresh foods C - Freezer calender (recommended storage times for frozen foods) D - Frozen food storage E - Dairy compartment (for dairy products to prevent tainting) F - Shelf with egg trays G - Can storage shelf H - Bottle storage shelf...
Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens.
The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Zanussi Service Force Centre whose address is listed in the Customer Care Booklet which accompanies your instruction manual.
TECHNICAL SPECIFICATIONS DIMENSIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY* GROSS CAPACITY NET CAPACITY STAR RATING * This figure is based on standard test results in accordance with European Standard EN153. Actual consumption will depend on how the appliance is used and where it is located. Height Width 59.5 cm...
Door reversibility Unplug the appliance from the power supply before carrying out the below-mentioned operations. Remove the ventilation grill (D). Unscrew the bottom hinge (E). Remove the freezer door by releasing it from the middle hinge (H). Unscrew the middle hinge. Remove the fridge door by releasing it from the top hinge pin (A).
OPERATION Refrigerator/Freezer - Starting-up and temperature regulation Insert the plug into the wall socket. Open the refrigerator door and turn the thermostat knob, to be found on the upper right side of the inner liner, clockwise, from the « O » position, to start the appliance.
HEALTH AND SAFETY GUIDELINES Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever. The following tips should help you to ensure that the food in your home is in as perfect condition as possible.
Freezing fresh food In any 24 hours you can freeze up to 3 kg. Place food to be frozen on the shelf of the freezer as this is the coldest part. The food to be frozen must be fresh and of the best quality.
Fresh food refrigeration To obtain the best performance, do not store warm food or evaporating liquids in the refrigerator; do cover or wrap the food, particularly if it has a strong flavour. Do not cover the shelves with any protective material, such as paper, cardboard or plastic, which may obstruct the air circulation through them.
Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be adjusted in height. To make these adjustments proceed as follows: Gradually pull the shelf in the direction of the arrows until it comes free, then reposition as required (Fig.
During everyday use a fridge door is opened many times and as a result temperature fluctuation may occur. A Zanussi fridge is designed to cope with any changes in temperature but under certain conditions the temperature guide in the appliance may show TOO WARM.
Defrosting Refrigerator The refrigerator automatically defrosts every time the compressor stops. Important To avoid defrost water overflowing into the fridge, periodically clean the water discharge hole in the centre of the V shaped drip collector at the back of the refrigerator compartment behind the fruit and vegetable drawer.
Page 17
Important When defrosting the freezer, the fridge is also controlled by the thermostat and will not be operational during this period. A temperature rise of the frozen food packs, during defrosting, may shorten their safe storage life. Attention! «In the event of a power failure causing the temperature within your freezer to rise, do not re- freeze the food without checking its condition.
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly.
Other points to check... If, after the above checks, there is still a fault, call your local Zanussi Service Centre, whose address can be found in the accompanying Customer Care Booklet, and can also be found in your local telephone directory under «Z».
Page 20
This guarantee is in addition to your statutory and other legal rights. We, Zanussi Ltd., undertake that if, within twelve months of the date of the purchase, this ZANUSSI appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials,...
