Olympus OMCL-AC160TS-W2 User Manual

Thank you for purchasing OLYMPUS Micro cantilever.
Please read this manual carefully before use.
＜Explanation of the each part of the products＞
Cantilever chips in a plastic case are included with manual and spec. sheet in the box.
Poly-urethane foam
A cantilever wafer on a base silicon wafer is inside the plastic case.
Orientation flat of
the cantilever
Case label wafer
Case (closed) Case (open)
Case label
Products name
OMCL-AC160TS-W2
300
42
Inspection stamp
user's manual
user's manual 書
Manual and Specification sheet
Case for cantilever wafer
(in a blue plastic pack)
Cantilever
Orientation flat of
the cantilever wafer
Orientation flat of
the base silicon wafer
Magnified illust.
Frame
Lot Number
Support arm
Cantilever
- 1e -
Please obey the following to the OLYMPUS micro cantilevers
 Use protective eye glasses when handling to avoid
damage to the eyes from breakage of the cantilever
chips.
 Please handle our cantilevers carefully because they are fragile.
 Do not drop or shake the cantilever case. Even when the cantilever chips
are contained in the cantilever case, the cantilevers may break if the
case is handled roughly or jarred.
 It is recommended that precautions be taken to prevent damage to the
cantilever tips from electrostatic discharge.
Cantilever chip
(substrate)
 Be sure to store the cantilevers at room temperature and moderate
humidity.
 When discarding, please obey the laws and regulations in your country
and/or your company. These cantilevers are made of silicon and
aluminum.
Warning
Caution
Caution
Caution
Caution
Caution
- 2e -
