- Page 1 INSTRUCTION BOOKLET DISHWASHER ZT 617...
-
Page 2: Table Of Contents
CONTENTS Warnings ...............page Installation . -
Page 3: Warnings
Children should not be allowed to tamper with the controls or play with the product. During Use Zanussi dishwashers are designed to be used for washing normal household utensils. Items that are contaminated by petrol, paint, steel or iron debris, corrosive, acidic or alkaline chemicals are not to be washed in a dishwasher. -
Page 4: Installation
INSTALLATION Remove all packaging before positioning the machine. Positioning If possible, position the machine next to a water tap and a drain. The dishwasher features fill and drain hoses which can be turned either to the left or the right to suit the installation . -
Page 5: The Electrical Connections
The cover/carrier is indicated by the coloured in- sert at the base of the plug. A replacement cover/carrier must be obtained from your local Zanussi Service Force Centre whose address is listed in the Customer Care Booklet which accompanies your instruction manual. -
Page 6: Use
Control panel THE CONTROLS The controls are located on top of the door. When se- lecting a programme, the door needs to be partially opened. Audible signals indicate which operations the dishwasher is performing. Short «instruction accepted» signal When any of the buttons are pressed: a short audible signal informs you that the machine has accepted the instruction given;... - Page 7 5. PROGRAMME SELECTION button To select the required programme, press this button until the number corresponding to the chosen pro- gramme appears in the digital display (4) (see wash programme guide). To start the programme, simply close the dishwasher door. A long audible signal (about one second) informs you that the programme is starting.
- Page 8 The Water Softener Water contains varying amounts of lime and mineral salts depending on the area in which you live: these are deposited on the dishes leaving white marks. The higher the content of these salts, the harder your water will be. The «hardness» level is measured on 3 equivalent scales: French Degrees, German Degrees or Parts Per Million.
- Page 9 Using no more than the correct amount of detergent also contributes to reducing pollution. Zanussi recommends the use of FINISH dishwasher detergent. Phosphate free detergents with enzymes These new detergents, although welcome from an ecological point of view, react far more susceptibly to water hardness than conventional products.
-
Page 10: Loading The Machine, Use Of The Lower Basket, Use Of The Upper Basket
Loading your Machine Before placing dishes in the machine, remove any scraps of food from the plates (small bones, toothpicks, fish bones, scraps of meat and vegetables, fruit skins etc.) to avoid clogging the filters and consequently reducing performance. Open the door and slide out the baskets to load the dishes. -
Page 11: Adjusting The Height Of The Upper Basket
Caution When loading the dishes, ensure that you do not cover the water inlet funnel in the middle of the upper basket. US04 Before closing the door, ensure that the spray arms can rotate freely. HELPFUL HINTS For Best Washing Results: Before loading, remove all scraps of food and soak very heavily soiled pots and pans. -
Page 12: Washing Programmes
WASHING PROGRAMMES Recommended Pro- Degree of soil and programme type of load gramme Any. Partial load (to be com- pleted later in the day). Heavy soil. INTENSIVE Crockery, cutlery, pots and pans. Normal soil. Crockery, cutlery, pots and pans. PREWASH Normal soil NORMAL NO Crockery and cutlery,... -
Page 13: Operating Sequence
Operating Sequence 1 Check that the filters are clean (see cleaning instructions) 2 Switch on at the main supply 3 Depress the ON/OFF pushbutton In the display appears the number of the last pro- gramme selected and the «PROGRAMMES SELEC- TION»... -
Page 14: Maintenance And Cleaning
MAINTENANCE AND CLEANING Cleaning the Central Filter (After each wash) Scraps of food can sometimes accumulate in the cen- tral filter (A) and should be periodically removed by rinsing the filter under running water. To remove the filter, simply pull it outward by the handle. MA04 Once cleaned, refit the filter by pushing it back to its original position until it engages. -
Page 15: Prolonged Periods Of Non-Operation
Prolonged Periods of Non-Operation If you are not using the machine for any period of time you are advised to: unplug the appliance and turn off the water; fill the rinse aid dispenser; leave the door ajar to prevent the formation of unpleasant smells;... -
Page 16: Servicing
There is no air vent in the end of the drain hose. If after these checks the fault codes remain displayed or the fault codes A1, A2, A4 or A7 appear contact your local Zanussi Service Centre. For washing or drying problems, please carry out the checks listed below: The dishes are not clean (poor wash);... - Page 17 Please note that proof of purchase is required for any in-guarantee service calls. Service details - adhesive label When you return your guarantee card to Zanussi Ltd. you will receive an «Appliance Guarantee And Maintenance Record» together with an adhesive label (containing the telephone number of your local Zanussi Service Centre).
-
Page 18: Building-In
BUILDING-IN Building-in features This dishwasher is designed to be fitted under a kitchen counter or sink. In either case, it is essential that the recess dimensions indicated in the picture are followed. No further openings for venting of the dishwasher are required, but only to let the water fill and drain hoses and power supply cable pass through. - Page 19 Fixing to the adjacent units Insert the two fixing brackets into the slots provided in the top front part of the dishwasher, as shown in the figure. Secure the brackets to adjacent units using two 3,5 x 16 screws for each bracket.
-
Page 20: Peace Of Mind For Twentyfour Months
This guarantee is in addition to your statutory and other legal rights. We, Zanussi Ltd., undertake that if, within twenty four months of the date of the purchase, this ZANUSSI appliance or any part thereof is proved to be defective... - Page 24 152995 82/0 Printed in Italy 0/1096...
