- Page 1 Topvex SX03, SX04, SX06 Compact Air Handling Unit Installation description Corrigo ver. no. 1.2-1-00...
-
Page 2: Declaration Of Conformity
Declaration of Conformity Manufacturer Systemair AB Industrivägen 3 SE-73930 Skinnskatteberg SWEDEN Office: +46 222 440 00 Fax: +46 222 440 99 www.systemair.com hereby confirms that the following products: Air handling units Topvex SX03 HW Topvex SX03 EL Topvex SX04 HW... -
Page 3: Table Of Contents
Installation, operation and maintenance manual concerns air handling unit type Topvex SX manufactured by Systemair AB. It consists of basic instructions and recommendations concerning the design, installation, start-up and operation, which shall be obeyed to ensure proper and fail-free operation of the unit. -
Page 4: Dimensions And Weight
Dimensions and weight Topvex SX03 15R ½" 1320 1600 (mm) Weight 213 kg Fig. 1 _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description Original 205871 Systemair AB... -
Page 5: Topvex Sx04-Sx06
Topvex SX04-SX06 Topvex SX04 (mm) Topvex SX06 (mm) 1041 1127 1747 2000 Topvex SX04 Topvex SX06 Weight 260 kg 308 kg Fig. 2... -
Page 6: Component Description Topvex Sx
Filter, extract air Re-heater battery (HW/EL) Connection box Heat exchanger Model (mm) Topvex SX03 Fan, extract air Topvex SX04 Fan, supply air Topvex SX06 Bypass damper motor Drain trap Fig. 3 _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description 205871 Systemair AB... -
Page 7: Transport And Storage
All inlets and outlets have to be duct connected before starting the unit to prevent the possibility to come in contact with moving parts. Handle and hinges are removable. Inspection doors can be opened without handles by using a 16mm cap key _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description 205871 Systemair AB... -
Page 8: Condensation Drain
(circular ducts) and 4 M8 bolts per joint (rectangular ducts). Rectangular ducts need sealing strips or sealing compound to ensure the air tightness. Silencers To avoid fan noise being transferred via the ducting system, silencers should be installed both on supply and extract air. _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description 205871 Systemair AB... -
Page 9: Condensation/Heat Insulation
Topvex SX 04 EL 230V 3~ 1520 12 kW 3x40 A Topvex SX 06 EL 230V 3~ 2104 16 kW 3x63 A Topvex SX 06 HW 230V 3~ 2104 ------- 3x13 A _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description 205871 Systemair AB... -
Page 10: External Connections
Supply voltage valve actuator, Heating Neutral Supply voltage valve actuator, Heating 24V AC Control signal water heating 0-10V DC * These inputs may only be wired to voltage free contacts. _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description 205871 Systemair AB... -
Page 11: Supply Air Sensor
NB: When installing a cooling battery the supply air sensor has to be installed in the duct after the cooling battery and connected to terminals 11 & 12 in the connection box (fig 3). _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description 205871 Systemair AB... -
Page 12: Hw Valve/Actuator
Heat exchanger Accessories (dashed components) Designation Component description Damper outdoor air Damper exhaust air Water cooling battery Water valve actuator Fig. 7 (The images show a right hand side unit) _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description 205871 Systemair AB... -
Page 13: Heat Exchanger
If the temperature drops and there is a risk of freezing (outlet water temperature below 8°C) the water flow is maintained (the valve will open fully), the fans stop and the outdoor/exhaust air damper, accessory, closes instantaneously. Fig. 9 shows two possible solutions for designing the water regulation. _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description 205871 Systemair AB... -
Page 14: Control Panel
(fig. 10). Description Description Alarm button Connection block Alarm LED Yellow cable Write enable LED Orange cable OK button Red cable Clearing button Brown cable Mounting holes Black cable Fig. 10 _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description 205871 Systemair AB... -
Page 15: How To Operate
See operating and maintenance instructions, "Operation". Set present time and date, set the medium and low airflow and program the week schedule. Check that: - there is no unusual noise from the unit. - control panel and lamp signals are in function _________________________________________________________________________________________________________ Topvex SX03, SX04, SX06 Installation description 205871 Systemair AB... - Page 16 Systemair AB reserves the right to make changes and improvements to the contents of this manual without prior notice. Systemair AB Industrivägen 3 SE-739 30 Skinnskatteberg, Sweden Phone +46 222 440 00 Fax +46 222 440 99 www.systemair.com 205871 (08-07-2011)
