Zanussi 531338 Specifications

RANGE
COMPOSITION
The MEDIUM NERT10 range consists of 2
electric models with one wash tank and one
speed with right or left-hand loading and a
maximum capacity of 100 baskets per hour.
All MEDIUM RT dishwashers are supplied as
standard with a Condensing Unit which
makes it unnecessary to install an extraction
hood, provided that the incoming water
temperature to the unit is equal or less
than10°C, as the machine guarantees air
emission at a temperature of no more than
30°C.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
Wash tank in 316 AISI stainless steel with
�
rounded corners, internal and external
surfaces in 304 AISI stainless steel. Wash
arms and jets in 304 AISI stainless steel to
ensure an excellent and reliable
performance. The double-skinned
counter-balanced inspection doors guarantee
solidity and strength.
Wash Zone: all the soil is removed by the
�
combination of the mechanical washing
action that directs water at the washware by
means of a powerful 700 litres/minute pump
and the thermal action of the heating
elements that guarantee a constant water
temperature of between 55° and 65°C and to
which the appropriate detergents are added.
Rinse Zone: clean water is used to
�
eliminate any trace of detergent from the
washware. There is a temperature control
device in the tank that guarantees the
sanitization of the washware at a
temperature of no less than 85°C.
Ease of Cleaning and Maintenance:
�
manually removable wash arms and tank
filters without the use of tools; water and
electrical connections are positioned centrally
on the front side of the machine to allow
installation directly against a wall.
Maximum Operator Safety: the machine is
�
RACK TYPE DISHWASHERS
completely automated and stops if the doors
are accidentally or deliberately opened, there
are no baskets in the machine, the wash
pump malfunctions or the electric elements
overheat.
MEDIUM NERT10 dishwashers can be
�
equipped with: a Rinse Booster pump to
increase rinse water pressure and Side
Wash Arms, as well as a vast range of
baskets 500 x 500 mm to suit any
requirements.
The MEDIUM NERT10 dishwashers can
�
TECHNICAL DATA
CHARACTERISTICS
Power supply
Feeding direction
N° of speeds
Capacity dishes/h
Air emission - m³/h
Air temperature - °C
External dimensions - mm
width
depth
height/with open door
1st wash
temperature - °C
tank capacity - lt.
pump power - kW
Rinsing
temperature - °C
boiler capacity - lt.
boiler power - kW
Power - kW
installed-electric
Noise level - dBA
Net weight - kg.
Supply voltage
INCLUDED ACCESSORIES
CONNECTION PLATE-HANDLING TO WT90/RT10
MEDIUM NERT10
be connected to specific pre-wash tabling,
entry and exit service tabling, roller conveyor
tabling and conveyor belts.
All models comply with the standards
�
required by the main international approval
bodies (VDE & DVGW) and are H marked.
* Declared actual cycle duration times can extend
when water supply temperature is lower than indicated
* Installation is recommended below a dishwashing
hood to convey steam.
NERT10ERC
533330
Electric
from RH to LH
1
1800
500
25
1550
824
1924, 2050
55-65
114
1.5
80-90
16
21
32.1
70
270
400 V, 3N, 50
2
533331
ZANUSSI
P R O F E S S I O N A L
MODELS
NERT10ELC
533331
Electric
from LH to RH
1
1800
500
25
1550
824
1924, 2050
55-65
114
1.5
80-90
16
21
32.1
70
270
400 V, 3N, 50
2
